Oval EL4101 - Temp.;Press. Correction Setup (T;P COMPNSATE); Temp.;Press. Correction Submenu Screen; ① Temp.;Press. Correction Ref. Temperature Setup (REF. TEMP.)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

Ｔ／Ｐ ＣＯＭＰＥＮ．       


ＲＥＦ． ＴＥＭＰ．         
         ＋１．５００００ Ｅ＋１
                     
                     
                     
＋１．５００００  
       Ｅ＋１
−−−−−−＜ＩＮＰＵＴＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

Ｔ／Ｐ ＣＯＭＰＥＮ．       

・ＲＥＦ． ＴＥＭＰ．         
         ＋１．５００００ Ｅ＋１
 ・ＲＥＦ． ＰＲＥＳＳ．        
         ＋０．０００００ Ｅ＋０
                     
                     
                     
                     
                     
−−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ
E-880TM-3-E
83
6.4.10 Temperature/Pressure Compensation Setup (T/P COMPEN.)
As parameters associated with temperature and pressure compensation, the reference temperature and
pressure are set up here.
＜Calculation formula＞
where ｔ：Line temperature（℃）
ｔ
０
：Correction reference temperature（℃）
p ：Line pressure（MPa)
p
0
：Correction reference pressure（MPa)
（1） T/P compensation submenu screen
At the submenu, move the cursor to the desired setup item with the up and down arrow keys.
At the touch of function key “ENTR”, the screen switches to the desired setup screen.
① T/P compensation reference temp. setup (REF. TEMP.) p. 83
② T/P compensation reference press. setup (REF. PRESS.) p. 84
To the setup screen pointed by the cursor
SET mode main menu screen ⇒ 6.2 SET mode main menu screen p. 36
K＝ ×
p ＋ 0.101325
p
0
＋ 0.101325
t
0
＋ 273.15
t ＋ 273.15
① Temperature/pressure compensation – reference temperature setup (REF. TEMP.)
The reference temperature of T/P compensation is set up here.
T/P correction submenu screen p. 83
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ For the unit to be set here, the measurement unit set in the temperature
input unit setup (① Temperature input unit setup (UNIT) on page 51) is
used. Make sure of the unit before you set up.
