Oval EL4101 - EL4301 Density Computer for Mass Flowmeter; EL4311 Density Computer for Mass Flowmeter (Solids Content Flow Compensated)

                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＰＡＳＳＷＯＲＤ          
 ＊ＣＡＬＥＮＤAＲ           
 ＊ＳＩＭＵＬＡＴＥ           
 ＊ＴＥＭＰ． ＩＮＰＵＴ        
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ３      
 ＊ＤＥＮＳＩＴＹ ＩＮＰＵＴ      
 ＊ＡＮＡＬＯＧ ＯＵＴＰＵＴ       
 ＊ＢＡＣＫＬＩＧＨＴ 
 ＊ＲＵＮ ＰＡＧＥ  
 ＊ＣＯＭＭＵＮICATION    
−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ
                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＰＡＳＳＷＯＲＤ          
 ＊ＣＡＬＥＮＤAＲ           
 ＊ＳＩＭＵＬＡＴＥ           
 ＊ＴＥＭＰ． ＩＮＰＵＴ        
 ＊ＤＥＮＳＩＴＹ ＩＮＰＵＴ      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ１      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ２      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ３      
 ＊ＡＮＡＬＯＧ ＯＵＴＰＵＴ      
 ＊ＴＯＴＡＬ ＣＯＵＮＴ ＲＥＳＥＴ  
↓−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ
                     
                     
↑−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＢＡＣＫＬＩＧＨＴ         
 ＊ＲＵＮ ＰＡＧＥ  
 ＊ＣＯＭＭＵＮICATION    






      
−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ 
                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＰＡＳＳＷＯＲＤ          
 ＊ＣＡＬＥＮＤAＲ           
 ＊ＳＩＭＵＬＡＴＥ           
 ＊ＴＥＭＰ． ＩＮＰＵＴ        
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ３      
 ＊ＤＥＮＳＩＴＹ ＩＮＰＵＴ      
 ＊ＡＮＡＬＯＧ ＯＵＴＰＵＴ       
 ＊ＢＡＣＫＬＩＧＨＴ 
 ＊ＲＵＮ ＰＡＧＥ  
 ＊ＣＯＭＭＵＮICATION    
−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ
                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＰＡＳＳＷＯＲＤ          
 ＊ＣＡＬＥＮＤAＲ           
 ＊ＳＩＭＵＬＡＴＥ           
 ＊ＴＥＭＰ． ＩＮＰＵＴ        
 ＊ＤＥＮＳＩＴＹ ＩＮＰＵＴ      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ１      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ２      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ３      
 ＊ＡＮＡＬＯＧ ＯＵＴＰＵＴ      
 ＊ＴＯＴＡＬ ＣＯＵＮＴ ＲＥＳＥＴ  
↓−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ
                     
                     
↑−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＢＡＣＫＬＩＧＨＴ         
 ＊ＲＵＮ ＰＡＧＥ  
 ＊ＣＯＭＭＵＮICATION    






      
−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ 
E-880TM-3-E
1
7.3.7 EL4301 Density Computer for Mass Flowmeter
7.3.8 EL4311 Density Computer for Mass Flowmeter
(solids content flowrate calculator equipped)
＊PASSWORD (password setup) p. 150
＊CALENDAR (calendar setup) p. 152
＊SIMULATE (analog output simulate) p. 153
＊TEMP. INPUT (temperatuare input setup) p. 154
＊PULSE OUTPUT 3 (pulse output 3 setup) p. 157
＊DENSITY INPUT (density input setup) p. 156
＊ANALOG OUTPUT (analog output setup) p. 159
＊BACKLIGHT (backlight setup) p. 161
＊RUN PAGE SAVE (run mode page setup save) p. 163
＊COMMUNICATION (communication setup)
※ Model with com interface p. 166
＊PASSWORD (password setup) p. 150
＊CALENDAR (calendar setup) p. 152
＊SIMULATE (analog output simulate) p. 153
＊TEMP. INPUT (temperature input setup) p. 154
＊PULSE OUTPUT 1 (pulse output 1 setup) p. 157
＊PULSE OUTPUT 2 (pulse output 2 setup) p. 157
＊PULSE OUTPUT 3 (pulse output 3 setup) p. 157
＊DENSITY INPUT (density input setup) p. 156
＊ANALOG OUTPUT (analog output setup) p. 159
＊TOTAL COUNT RESET (total counter reset setup) p. 160
＊BACKLIGHT (backlight setup) p. 161
＊RUN PAGE SAVE (RUN mode page setup save) p. 163
＊COMMUNICATION (communication setup)
※ model with com interface p. 166
