Oval EL4101 - EL4211 Liquid Temperature Compensated Flow Computer (Measured in Terms of Mass); EL4301 Density Computer for Mass Flowmeter; EL4311 Density Computer for Mass Flowmeter (Solids Content Flow Compensated)









                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

＊ＴＥＭＰ． ＩＮＰＵＴ
 ＊ＤＥＮＳ．ＰＵＬＳＥ ＩＮＰＵＴ 
 ＊ＡＮＡＬＯＧ ＯＵＴＰＵＴ      
 ＊ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ
                     

                     


                     
−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
 ＰＬＳＥ｜ＣＡＮ−｜    ｜     
  ＳＥＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

＊ＴＥＭＰ． ＩＮＰＵＴ
 ＊ＰＵＬＳＥ ＩＮＰＵＴ        
 ＊ＦＬＯＷ ＲＡＴＥ ＳＥＴＴＩＮＧ
 ＊ＤＥＮＳ．ＰＵＬＳＥ ＩＮＰＵＴ 
 ＊ＴＯＴＡＬ ＣＯＵＮＴ      
 ＊ＴＯＴＡＬ ＣＯＵＮＴ（ＳＯＬＩＤ）
 ＊ＡＮＡＬＯＧ ＯＵＴＰＵＴ      
 ＊ＭＥＴＥＲ ＥＲＲＯＲ        
 ＊ＦＬＯＷ（ＳＯＬＩＤ）ＰＡＲＡ．   
 ＊ＦＬＯＷ ＲＡＴＥ     
↓−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
 ＰＬＳＥ｜ＣＡＮ−｜    ｜     
  ＳＥＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

＊ＴＥＭＰ． ＩＮＰＵＴ       
 ＊ＰＵＬＳＥ ＩＮＰＵＴ 
 ＊ＦＬＯＷ ＲＡＴＥ ＳＥＴＴＩＮＧ
 ＊ＴＯＴＡＬ ＣＯＵＮＴ       
 ＊ＴＯＴＡＬ ＣＯＵＮＴ（Ｃ）    
 ＊ＡＮＡＬＯＧ ＯＵＴＰＵＴ     
 ＊ＭＥＴＥＲ ＥＲＲＯＲ       
 ＊ＦＬＯＷ ＲＡＴＥ
 ＊ＦＬＯＷ ＲＡＴＥ（Ｃ）    
 ＊ＴＥＭＰ． ＣＯＭＰＥＮ． 
↓−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
 ＰＬＳＥ｜ＣＡＮ−｜    ｜     
  ＳＥＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
／                    
↑−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

＊ＤＥＮＳＩＴＹ









−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
 ＰＬＳＥ｜ＣＡＮ−｜    ｜     
  ＳＥＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
E-880TM-3-E
3
＊TEMP. INPUT (temperature input setup) p. 48
＊PULSE. INPUT (pulse input setup) p. 66
＊FLOW RATE SETTING (instant flowrate measurement setup) p. 67
＊TOTAL COUNT (total count setup) p. 74
＊TOTAL COUNT (C) (total count (corrected mass) setup) p. 74
＊ANALOG OUTPUT (analog output setup) p. 76
＊METER ERROR (meter error correction setup) p. 85
＊FLOW RATE (instant flowrate calculation setup) p. 95
＊FLOW RATE (C) (instant flowrate (corrected mass setup) p. 95
＊TEMP. COMPENSATE (temperature correction factor setup) p. 83
（6）EL4211 Liquid Temperature Compensated Flow Computer
(measured in terms of mass)
＊TEMP. INPUT (temperature input setup) p. 48
＊DENSITY PULSE. INPUT (density pulse input setup) p. 72
＊ANALOG OUTPUT (analog calculation setup) p. 76
＊DENSITY PARAMETER (density calculation setup) p. 102
（7）EL4301 Density Computer for Mass Flowmeter
＊TEMP. INPUT (temperature input setup) p. 48
＊PULSE. INPUT (pulse input setup) p. 66
＊FLOW RATE SETTING (instant flowrate measurement setup) p. 67
＊DENS. PULSE INPUT (density input setup) p. 72
＊TOTAL COUNT (total count setup) p. 74
＊TOTAL COUNT (SOLID) (total count (solids content) setup) p. 74
＊ANALOG OUTPUT (analog output setup) p. 76
＊METER ERROR (meter error correction setup) p. 85
＊FLOW (SOLID) PARA. (solids content flow calculation setup) p. 120
＊FLOW RATE (C) (instant flowrate correction setup) p. 95
（8）EL4311 Density Computer for Mass Flowmeter
(solids content flow compensated)
＊DENSITY (density setup) p. 100
