Oval EL4101 - ⑥ Communication Terminate Setup (TERMINATE); ⑦ Communication BCC Setup (BCC); ⑧ Communication Parity Bit Setup (PARITY)

                     
       Ａ−Ｌ             
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

ＣＯＭＭＵＮＩＣＡＴＩＯＮ       


ＴＥＲＭＩＮＡＴＥ  
                ＣＲ＋ＬＦ

１：ＮＯＮＥ    
 ２：ＬＦ         
 ３：ＣＲ      
 ４：ＣＲ＋ＬＦ  
      
                  
                 
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
       Ａ−Ｌ             
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

ＣＯＭＭＵＮＩＣＡＴＩＯＮ       


ＢＣＣ  
                  ＢＣＣ

１：ＮＯＮＥ    
 ２：ＳＵＭ         
 ３：ＢＣＣ     
   
      
                  
                 
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
       Ａ−Ｌ             
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

ＣＯＭＭＵＮＩＣＡＴＩＯＮ       


ＰＡＲＩＴＹ  
                 ＥＶＥＮ

１：ＮＯＮＥ    
 ２：ＯＤＤ        
 ３：ＥＶＥＮ   
   
      
                  
                 
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
E-880TM-3-E
1
Communication setup submenu screen p. 166
⑥ Communication terminator setup (TERMINATE)
Communication terminator is set up here.
Communication setup submenu screen p. 166
⑦ Communication BCC setup (BCC)
Communication BCC is set up here.
Communication setup submenu screen p. 166
⑧ Communication parity bit setup (PARITY)
Communication parity bit is set up here.
←Data bit length option select
For details of option setup, see “(2) Option select setup screen (SELECT)” on
page 46.
←Data bit length option select (setup)
For details of option setup, see “(2) Option select setup screen (SELECT)” on
page 46.
←Data bit length option select (setup)
For details of option setup, see “(2) Option select setup screen (SELECT)” on
page 46.
