Oval EL4101 - EL4501 Multipoint Temperature Compensated Flow Computer

                     
／                    
ＴＯＴＡＬ ＣＯＵＮＴ（Ｑ）    １／４
         ０
                    ｌ
ＴＯＴＡＬ ＣＯＵＮＴ（Ｑμｆ）   
         ０
                    ｌ
ＴＯＴＡＬ ＣＯＵＮＴ（Ｑμｆρ） 
         ０
                    ｌ
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜     
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜    
                     
／                    
ＴＥＭＰＥＲＡＴＵＲＥ       ２／４
     １０．００
                   Ｃ 
ＳＥＴ ＤＥＮＳＩＴＹ（ρ）       
     １．０００
                ｇ／ｃｍ３
ＳＥＴ ＶＩＳＣＯＳＩＴＹ（μ）
       １．０
                   mPa・s
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
ＯＶＥＲＡＬＬ ＥＲＲＯＲ     ３／４
    ４．７４００
                    
ＶＣＦ                 
    １．００００
                     

  
  
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
Ｅ１                ４／４
    １．００００
                    
Ｅ２                  
    １．００００
                     
ＦＲＥＱＵＥＮＣＹ
    １．００００
                   Ｈｚ
 ＭＯＤＥ｜ＥＲＲ．｜    ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜    ｜ＤＯＷＮ
E-880TM-3-E
3
5.4.11 EL4501 Multipoint Temperature Compensated Flow Computer
←RUN mode screen 1
Pressing function key “PAGE UP” switches the screen to the next screen.
“TOTAL COUNT (Q)”: Uncorrected total flow
“TOTAL COUNT (Qμf)”: Total flow corrected for viscosity
“TOTAL COUNT (Qμfρ)”: Total flow corrected for temperature and viscosity
※ Measurement units, exponent, and indicated values vary with actual
settings (SET mode).
←RUN mode screen 2
Pressing function key “PAGE UP” switches the screen to the next screen.
“TEMPERATURE”: Temperature
“SET DENSITY (ρ)”: Density set (ρ)
“SET VISCOSITY (μ)”: Viscosity set (μ)
※ The placement of decimal point in temperature, density, and viscosity
readings varies with the measurement units selected. (For the decimal
point of temperature, see “① Temperature input unit setup (UNIT)” on
page 51. For the decimal point of density, see “① Density parameter unit
setup (UNIT)” on page 130. For the decimal point of viscosity, see
“① Viscosity correction (μ) unit setup (UNIT)” on page 135.)
←RUN mode screen 3
Pressing function key “PAGE DOWN” switches the screen to the previous screen.
“OVERALL ERROR”: Overall error
“VCF”: Volume conversion factor
←RUN mode screen 4
Pressing function key “PAGE DOWN” switches the screen to the previous screen.
“E1”: Meter error correction factor dependent on flow velocity and viscosity
“E2”: 3α correction factor
“FREQUENCY”: Pulse input frequency
