Oval EL4101 - EL4511 Multipoint Temperature Compensated Flow Computer (with Com Interface)

                     
／                    
ＴＯＴＡＬ ＣＯＵＮＴ（Ｑ）    １／４
         ０
                    ｌ
ＴＯＴＡＬ ＣＯＵＮＴ（Ｑμｆ）   
         ０
                    ｌ
ＴＯＴＡＬ ＣＯＵＮＴ（Ｑμｆρ） 
         ０
                    ｌ
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜     
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜    
                     
／                    
ＴＥＭＰＥＲＡＴＵＲＥ       ２／４
     １０．００
                   Ｃ 
ＳＥＴ ＤＥＮＳＩＴＹ（ρ）       
     １．０００
                ｇ／ｃｍ３
ＳＥＴ ＶＩＳＣＯＳＩＴＹ（μ）
       １．０
                  
mPa・s
 
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
Ｅ１                ４／４
    １．００００
                    
Ｅ２                  
    １．００００
                     
ＦＲＥＱＵＥＮＣＹ
    １．００００
                   Ｈｚ
 ＭＯＤＥ｜ＥＲＲ．｜    ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜    ｜ＤＯＷＮ
                     
／                    
ＯＶＥＲＡＬＬ ＥＲＲＯＲ     ３／４
    ４．７４００
                    
ＶＣＦ                 
    １．００００
                     

  
  
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
E-880TM-3-E
3
5.4.12 EL4511 Multipoint Temperature Compensated Flow Computer
(communication interface provided)
←RUN mode screen 1
Pressing function key “PAGE UP” switches the screen to the next screen.
“TOTAL COUNT (Q)”: Uncorrected total flow
“TOTAL COUNT (Qμf)”: Viscosity corrected total flow
“TOTAL COUNT（Qμfρ）”: Viscosity/temperature corrected total flow
※ The measuring unit, exponent, and readings vary with actual configuration
settings (in the SET mode).
←RUN mode screen 2
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing the function key “PAGE DOWN” switches the screen to the previous
screen.
“TEMPERATRE”: Temperature
“SET DENSITY (ρ)”: Density set (ρ)
“SET VISCOSITY (μ)”: Viscosity set (μ)
※ The placement of decimal point depends on the measurement unit selected.
(For the decimal point of temperature, see “① Temperature input unit setup
(UNIT)” on page 51. For the decimal point of density, see “① Density
parameter unit setup (UNIT)” on page 130. For the decimal point of viscosity,
see “① Viscosity correction (μ) unit setup (UNIT)” on page 135.)
←RUN mode screen 3
Pressing (the) function key “PAGE DOWN” switches the screen to the previous
screen.
“OVERALL ERROR”: Overall meter error
“VCF”: Volume conversion factor
←RUN mode screen 4
Pressing function key “PAGE DOWN” switches the screen to the previous screen.
“E1”: Meter error correction factor relative to fluid velocity and viscosity
“E2”: 3α correction factor
“FREQUENCY”: Pulse input frequency
