Oval EL4101 - EL4321 Density Computer (Oscillating Spool Densitometer, Gas Service); EL4401 Blend Oil Temperature Compensated Flow Computer

                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＰＡＳＳＷＯＲＤ          
 ＊ＣＡＬＥＮＤAＲ           
 ＊ＳＩＭＵＬＡＴＥ           
 ＊ＴＥＭＰ． ＩＮＰＵＴ        
 ＊ＰＲＥＳＳ． ＩＮＰＵＴ       
 ＊ＤＥＮＳＩＴＹ ＩＮＰＵＴ      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ１     
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ２     
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ３      
 ＊ＢＡＣＫＬＩＧＨＴ         
↓−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ
                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＰＡＳＳＷＯＲＤ          
 ＊ＣＡＬＥＮＤAＲ           
 ＊ＳＩＭＵＬＡＴＥ           
 ＊ＴＥＭＰ． ＩＮＰＵＴ        
 ＊ＢＬＥＮＤ ＩＮＰＵＴ       
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ１      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ２      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ３      
 ＊ＴＯＴＡＬ ＣＯＵＮＴ ＲＥＳＥＴ  
 ＊ＢＡＣＫＬＩＧＨＴ         
↓−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ
                     
                     
↑−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＲＵＮ ＰＡＧＥ 
 ＊ＣＯＭＭＵＮICATION    
  






      
−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ 
                     
                     
↑−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＲＵＮ ＰＡＧＥ  
 ＊ＣＯＭＭＵＮICATION    







      
−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ 
E-880TM-3-E
18
7.3.9 EL4321 Density Computer (oscillating spool densitometer, gas service)
7.3.10 EL4401 Blend Oil Temp. Compensated Flow Computer
＊ PASSWPRD (password setup) p. 150
＊ CALENDAR (calendar setup) p. 152
＊ SIMULATE (analog output simulate) p. 153
＊ TEMP. INPUT (temperatuare input setup) p. 154
＊ BLEND INPUT (blend input setup) p. 165
＊ PULSE OUTPUT 1 (pulse output 1 setup) p. 157
＊ PULSE OUTPUT 2 (pulse output 2 setup) p. 157
＊ PULSE OUTPUT 3 (pulse output 3 setup) p. 157
＊ TOTAL COUNT RESET (total counter reset setup) p. 160
＊ BACKLIGHT (backlight setup) p. 161
＊PASSWPRD (password setup) p. 150
＊CALENDAR (calendar setup) p. 152
＊SIMULATE (analog output simulate) p. 153
＊TEMP. INPUT (temperatuare input setup) p. 154
＊PRESS. INPUT (pressure input setup) p. 155
＊DENSITY INPUT (density input setup) p. 156
＊PULSE OUTPUT 1 (pulse output 1 setup) p. 157
＊PULSE OUTPUT 2 (pulse output 2 setup) p. 157
＊PULSE OUTPUT 3 (pulse output 3 setup) p. 157
＊BACKLIGHT (backlight setup) p. 161
＊RUN PAGE SAVE (RUN mode page setup save) p. 163
＊COMMUNICATION (communication setup)
※ model with com interface p. 166
＊ RUN PAGE SAVE (RUN mode page setup save) p. 163
＊ COMMUNICATION (communication setup)
※ model with com interface p. 166
