Oval EL4101 - ③ Viscosity Compensation (Μ) - over Alarm Point Setup (over ALARM POINT); ④ Viscosity Compensation (Μ) - Viscosity Μ1 Setup (Μ1); ⑤ Viscosity Compensation (Μ) - Viscosity Μ2 Setup (Μ2)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＶＩＳＣＯＳＩＴＹ ＣＯＭＰ．（μ）


ＯＶＥＲ ＡＬＡＲＭ ＰＯＩＮＴ   
         ＋１．１５０００ Ｅ＋３
                     
                     
                     
＋１．１５０００  
       Ｅ＋３
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＶＩＳＣＯＳＩＴＹ ＣＯＭＰ．（μ）  


μ１  
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＶＩＳＣＯＳＩＴＹ ＣＯＭＰ．（μ）


μ２   
         ＋１．０００００ Ｅ＋０
                     
                     
                     
＋１．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
E-880TM-3-E
13
③ Viscosity compensation (μ) - over alarm point setup (OVER ALARM POINT)
The viscosity over alarm point to be set in the parameter setup mode is set up here.
Viscosity compensation ( μ ) submenu screen p. 134
④ Viscosity compensation (μ) - viscosity μ1 setup (μ1)
Coefficient μ1 in viscosity compensation is set up here.
Viscosity compensation ( μ ) submenu screen p. 134
⑤ Viscosity compensation (μ) - viscosity μ2 setup (μ2)
Coefficient μ2 in viscosity compensation is set up here.
Viscosity compensation ( μ ) submenu screen p. 134
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ For the unit to be set here, the unit set at the unit setup of viscosity
compensation (① Viscosity compensation (μ) unit setup (UNIT) on page
135) is used. Make sure of the unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ For the unit to be set here, the unit set at the unit setup of viscosity
compensation (① Viscosity compensation (μ) unit setup (UNIT) on page
135) is used. Make sure of the unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ For the unit to be set here, the unit set at the unit setup of viscosity
compensation (① Viscosity compensation (μ) unit setup (UNIT) on page
135) is used. Make sure of the unit before you set up.
