Oval EL4101 - ⑤ Density Calculation - under Fallback Level Setup (under FALLBACK); ⑥ Density Calculation - over Fallback Level Setup (over FALLBACK); ⑦ Density Calculation - Measuring System Select (MEASURE SEL.)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＵＮＤＥＲ ＦＡＬＬＢＡＣＫ    
         ＋１．０００００ Ｅ−２
                     
                     
                     
＋１．０００００  
       Ｅ−２
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＭＥＡＳＵＲＥ． ＳＥＬ．      
                 ＧＡＳＳ

１：ＧＡＳＳ              
 ２：ＧＡＳＳ（Ｃ）           
                     
                     
                     
                     
                     
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＯＶＥＲ ＦＡＬＬＢＡＣＫ     
         ＋２．０００００ Ｅ＋０
                     
                     
                     
＋２．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
E-880TM-3-E
1
⑤ Density calculation - under fallback level setup (UNDER FALLBACK)
The under fallback level with respect to the uncorrected density is set up here.
Density calculation submenu screen p. 123
⑥ Density calculation - over fallback level setup (OVER FALLBACK)
The over fallback level with respect to the uncorrected density is set up here.
Density calculation submenu screen p. 123
⑦ Density calculation – measurement type selection (MEASURE. SEL.)
The density measurement type is set up here. When “GASS” is your selection, the computer shows
the corrected density, provides an analog output as the uncorrected density and shows its reading.
Density calculation submenu screen p. 123
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the density input in the SYS mode (① Density input type setup (TYPE)
on page 156), this item is not shown unless the input type is set to NONE.
※ For the unit to be set here, the unit set at the density unit setup in density
calculation (① Density calculation unit setup (UNIT) on page 125) is used.
Make sure of the unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the density input in the SYS mode (① Density input type setup (TYPE)
on page 156), this item is not shown unless the input type is set to NONE.
※ For the unit to be set here, the unit set at the density unit setup in density
calculation (① Density calculation unit setup (UNIT) on page 125) is used.
Make sure of the unit before you set up.
←Measurement type select
Details of measurement type selection, see “(2) Option select setup screen
(SELECT)” on paghe 46.
