Oval EL4101 - When Parameter Setup Card Is Inserted


／ ＣＤ
−−−−−＜ＭＯＤＥ ＭＥＮＵ＞−−−−−
             ０７−０６−１３
                １３：４７


     ＭＯＤＥＬ：ＥＬ４１２１
      Ｔ／Ｐ ＣＯＭＰＥＮ．





 ＲＵＮ ｜ＳＥＴ ｜ＳＹＳ ｜ＰＲＭ
 ＭＯＤＥ｜ＭＯＤＥ｜ＭＯＤＥ｜ＣＡＲＤ
                     
／ ＣＤ                 
−＜ＩＣ ＣＡＲＤ ＳＵＰＰＯＲＴ ２＞−
ＭＯＤＥＬ：ＥＬ４１２１
ＶＥＲＳＩＯＮ：４．００         
ＰＡＲＡＭＥＴＥＲ：ＳＥＴ        
ＣＡＬＩＢＲＡＴＩＯＮ：ＯＫ       
                     
ＣＡＲＤ（ＰＡＲＡＭＥＴＥＲ）      
ＭＯＤＥＬ：ＥＬ４３００
ＶＥＲＳＩＯＮ：４．００         
     
 ＣＡＬＣＵＲＡＴＩＯＮ ＥＮＤ ？   
                     
 ＣＡＮ−｜    ｜    ｜     
  ＣＥＬ｜    ｜    ｜ＹＥＳ 
                     
  ＣＤ                 
−＜ＩＣ ＣＡＲＤ ＳＵＰＰＯＲＴ １＞−
ＭＯＤＥＬ：ＥＬ４１２１
ＶＥＲＳＩＯＮ：４．００         
ＰＡＲＡＭＥＴＥＲ：ＳＥＴ  
ＣＡＬＩＢＲＡＴＩＯＮ：ＯＫ       
                     
ＣＡＲＤ（ＰＡＲＡＭＥＴＥＲ）      
ＭＯＤＥＬ：ＥＬ４１２１
ＶＥＲＳＩＯＮ：４．００         
    
      ＣＨＡＮＧＥ ？       
                     
 ＣＡＮ−｜    ｜    ｜     
  ＣＥＬ｜    ｜ＬＯＡＤ｜ＳＡＶＥ
E-880TM-3-E

（2） When parameter setup card is inserted
When parameter setup card is popped into the drive, a label “PRM CARD” appears in the function key
field as shown below.
←Mode select menu screen
Upon depression of function key “PRM CARD”, the screen changes into IC card
support 2 screen.
(PRM CARD stands for PARAMETER CARD.)
←IC card support 1 screen
At the touch of function key “CANCEL”, the screen goes back to the mode select
menu screen.
Switching into the IC card support screen 1 causes the
computer to stop updating calculation.
←IC card support 2 screen
With parameter setup card, due to the need to interrupt calculation process, the
computer prompts the operator whether to interrupt calculation or not.
Pressing function key “YES” stops calculation and the screen switches to the IC
card support 1 screen.
At the touch of function key “CANCEL”, the screen goes back to the mode select
menu screen.
CAUTION:
※ If the model number set in the computer does not agree with the model
number stored in the card, function key label “LOAD” will not appear..
