Oval EL4101 - About On-Screen Submenu Items

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＴＥＭＰ． ＩＮＰＵＴ         

・ＵＮＩＴ               
                   ゜Ｃ
 ・ＢＡＳＥ ＳＣＡＬＥ         
         −５．０００００ Ｅ＋１
 ・ＦＵＬＬ ＳＣＡＬＥ         
         ＋３．５００００ Ｅ＋２
 ・ＵＮＤＥＲ ＡＬＡＲＭ ＰＯＩＮＴ  
         −５．０００００ Ｅ＋１
                     
↓−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＴＥＭＰ． ＩＮＰＵＴ         

・ＵＮＩＴ               
                   ゜Ｃ
 ・ＣＯＮＳＴＡＮＴ           
         ＋１．５００００ Ｅ＋１
                     
                     
                     
                     
                     
−−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ
E-880TM-3-E

6.3.2 About On-screen Submenu Items
On the submenu screen, submenu items corresponding to respecttive main menu items are shown. The
items shown here are only those necessary for setup with respect to the current settings; items not
necessary for setup are not shown.
Example: When the input type of temperature input in the SYM mode are 1 to 5V and NONE (constant),
the submenu items for temperature input setup in the SET mode, with the temperature input set at
“NONE”, will be the measurement unit and a constant. With the “1 to 5V” selected, on the other hand,
the measurement unit, baseline, full scale, under alarm point, over alarm point, under fallback level, and
over fallback level will be shown.
① Input type is 1 to 5V
② Input type is None (fixed value)
