Oval EL4101 - ⑤ Pressure Input under Alarm Point Setup (under ALARM POINT); ⑥ Pressure Input over Alarm Point Setup (over ALARM POINT); ⑦ Pressure Input under Fallback Level Setup (under FALLBACK)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＰＲＥＳＳ． ＩＮＰＵＴ        


ＵＮＤＥＲ ＦＡＬＬＢＡＣＫ    
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＰＲＥＳＳ． ＩＮＰＵＴ        


ＵＮＤＥＲ ＡＬＡＲＭ ＰＯＩＮＴ  
         −３．１２５００ Ｅ−１
                     
                     
                     
−３．１２５００  
       Ｅ−１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＰＲＥＳＳ． ＩＮＰＵＴ        


ＯＶＥＲ ＡＬＡＲＭ ＰＯＩＮＴ   
         ＋１．１２５００ Ｅ＋１
                     
                     
                     
＋１．１２５００  
       Ｅ＋１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
E-880TM-3-E

⑤ Pressure input under alarm point setup (UNDER ALARM POINT)
The under alarm point with respect to the pressure input is set up here.
⑥ Pressure input over alarm point setup (OVER ALARM POINT)
The over alarm point with respect to the pressure input is set up here.
⑦ Pressure input under fallback level setup (UNDER FALLBACK)
The under fallback level with respect to the pressure input is set up here.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown unless the pressure input type
(① Pressure input type setup (TYPE) on page 155) is set to”NONE”.
※ For the unit to be set here, the unit set at the pressure input unit setup
(① Pressure input unit setup (UNIT) on page 57) is used. Make sure of the
unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown unless the pressure input type
(① Pressure input type setup (TYPE) on page 155) is set to”NONE”.
※ For the unit to be set here, the unit set at the pressure input unit setup
(① Pressure input unit setup (UNIT) on page 57) is used. Make sure of the
unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown unless the pressure input type
(① Pressure input type setup (TYPE) on page 155) is set to”NONE”.
※ For the unit to be set here, the unit set at the pressure input unit setup
(① Pressure input unit setup (UNIT) on page 57) is used. Make sure of the
unit before you set up.
To press. input submenu screen p. 56
To press. input submenu screen p. 56
To press. input submenu screen p. 56
