Oval EL4101 - SET Mode Main Menu Screen by Model; EL4101 Steam Service Flow Computer (Saturated Steam Service); EL4111 Steam Service Flow Computer (Superheated Steam Service); EL4121 Temperature;Pressure Compensated Flow Computer (Gas Service)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

＊ＰＲＥＳＳ． ＩＮＰＵＴ
 ＊ＰＵＬＳＥ ＩＮＰＵＴ
 ＊ＦＬＯＷ ＲＡＴＥ ＳＥＴＴＩＮＧ
 ＊ＴＯＴＡＬ ＣＯＵＮＴ１
 ＊ＴＯＴＡＬ ＣＯＵＮＴ２
 ＊ＡＮＡＬＯＧ ＯＵＴＰＵＴ      
 ＊ＭＥＴＥＲ ＥＲＲＯＲ
 ＊ＳＰＥＣ． ＷＥＩＧＨＴ（ＳＡＴ）
 ＊ＳＰＥＣ． ＥＮＴＨＡＬＰＹ（ＳＡＴ）
 ＊ＦＬＯＷ ＲＡＴＥ
−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
 ＰＬＳＥ｜ＣＡＮ−｜    ｜     
  ＳＥＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

＊ＴＥＭＰ． ＩＮＰＵＴ
 ＊ＰＲＥＳＳ． ＩＮＰＵＴ
 ＊ＰＵＬＳＥ ＩＮＰＵＴ
 ＊ＦＬＯＷ ＲＡＴＥ ＳＥＴＴＩＮＧ
 ＊ＴＯＴＡＬ ＣＯＵＮＴ１
 ＊ＴＯＴＡＬ ＣＯＵＮＴ２
 ＊ＡＮＡＬＯＧ ＯＵＴＰＵＴ    
 ＊３α ＣＯＭＰＥＮ
 ＊ＭＥＴＥＲ ＥＲＲＯＲ
 ＊ＳＰＥＣ． ＷＥＩＧＨＴ（ＳＵＰ）
↓−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
 ＰＬＳＥ｜ＣＡＮ−｜    ｜     
  ＳＥＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

＊ＴＥＭＰ． ＩＮＰＵＴ
 ＊ＰＲＥＳＳ． ＩＮＰＵＴ
 ＊ＰＵＬＳＥ ＩＮＰＵＴ
 ＊ＦＬＯＷ ＲＡＴＥ ＳＥＴＴＩＮＧ
 ＊ＴＯＴＡＬ ＣＯＵＮＴ
 ＊ＴＯＴＡＬ ＣＯＵＮＴ（Ｃ）
 ＊ＡＮＡＬＯＧ ＯＵＴＰＵＴ      
 ＊３α ＣＯＭＰＥＮ．
 ＊Ｔ／Ｐ ＣＯＭＰＥＮ．
 ＊ＭＥＴＥＲ ＥＲＲＯＲ
↓−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
 ＰＬＳＥ｜ＣＡＮ−｜    ｜     
  ＳＥＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
／                    
↑−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

＊ＳＰＥＣ． ＥＮＴＨＡＬＰＹ（ＳＵＰ）
 ＊ＦＬＯＷ ＲＡＴＥ
 
 
 
 

 
      
  
−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
 ＰＬＳＥ｜ＣＡＮ−｜    ｜     
  ＳＥＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
E-880TM-3-E
3
＊PRESS. INPUT (pressure input setup) p. 65
＊PULSE. INPUT (pulse input setup) p. 66
＊FLOW RATE SETTING (instant flowrate measurement setup) p. 67
＊TOTAL COUNT 1 (total count 1 setup) p. 74
＊TOTAL COUNT 2 (total count 2 setup) p. 74
＊ANALOG OUTPUT (analog output setup) p. 76
＊METER ERROR (meter error correction setup) p. 85
＊SPEC. WEIGHT (SAT) (relative density (sp. weight) setup) p. 91
＊SPEC. ENTHALPY (SAT) (specific enthalpy setup) p. 93
＊FLOW RATE (instant flowrate setup) p. 95
6.2.1 SET Mode Main Menu Setup Items by Model
（1）EL4101 Steam Service Flow Computer (saturated steam service)
＊TEMP. INPUT (temperature input setup) p. 48
＊PRESS. INPUT (pressure input setup) p. 55
＊PULSE. INPUT (pulse input setup) p. 66
＊FLOW RATE SETTING (instant flowrate measurement setup) p. 67
＊TOTAL COUNT 1 (total count 1 setup) p. 74
＊TOTAL COUNT 2 (total count 2 setup) p. 74
＊ANALOG OUTPUT (analog output setup) p. 76
＊3α COMPENSATE (3α compensate setup) p. 80
＊METER ERROR (meter error correction factor setup) p. 85
＊SPEC. WEIGHT (SUP) (relative density (sp. weight) setup) p. 92
＊SPEC. ENTHALPY (SUP) (specific enthalpy setup) p. 94
＊FLOW RATE (instant flowrate setup) p. 95
＊TEMP. INPUT (temperature input setup) p. 48
＊PRESS. INPUT (pressure input setup) p. 55
＊PULSE. INPUT (pulse input setup) p. 66
＊FLOW RATE SETTING (instant flowrate measurement setup) p. 67
＊TOTAL COUNT 1 (total count 1 setup) p. 74
＊TOTAL COUNT (C) (total count (corrected) setup) p. 74
＊ANALOG OUTPUT (analog output setup) p. 76
＊3α COMPENSATE (3α compensate setup) p. 80
＊T/P COMPENSATE (temp./press. correction factor setup) p. 83
＊METER ERROR (meter error correction factor setup) p. 85
（2）EL4111 Steam Service Flow Computer (superheated steam service)
（3） EL4121 Temperature/Pressure Compensated Flow Computer (gas service)
