Oval EL4101 - ① Pressure Input Unit Setup (UNIT)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＰＲＥＳＳ． ＩＮＰＵＴ        


ＵＮＩＴ               
                  ＭＰａ

１：ｇ／ｃｍ２ 
 ２：kｇｆ／ｃｍ２              
 ３：Ｐａ               
 ４：ｋＰａ              
 ５：ＭＰａ            
 ６：ｂａｒ               
 ７：ｍｍＨ２Ｏ           
↓−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ 
E-880TM-3-E

Submenu item
SYS mode input type ※ NONE Other than NONE
Unit of measurement Displayed Displayed
Constant Displayed Hidden
Baseline Hidden Displayed
Full scale Hidden Displayed
Under alarm point Hidden Displayed
Over alarm point Hidden Displayed
Under fallback level Hidden Displayed
Over fallback level Hidden Displayed
Smoothing factor Hidden Displayed
Conditions to show submenu items
※：Conditions for selecting on-screen information
① Pressure input unit setup (UNIT)
Measurement unit of pressure input is selected here.
To press. input submenu
screen p. 56
Unit Number of decimal places
g/cm
2
0
kgf/cm
2
3
Pa 0
kPa 1
MPa 4
bar 3
mmH
2
O
0
psi
2
Number of decimal places for each unit
←Unit option select
For details of measurement unit selection, see “(2) Measurement unit selection
(SELECT)” on page 46.
Available units in pressure input are “g/cm
2
”, “kgf/cm
2
”, “Pa”, “kPa”, “MPa”, “bar”,
“mmH2O”, and “psi” and are common to all models.
※ As the measurement unit is changed, the current values (baseline, full
scale setpoint, etc.) are converted automatically to read in the new
measurement unit chosen.
※ The unit to be set here implies that of the pressure displayed in the RUN
mode and of the pressure to be set by the pressure input in the SET
mode.
※ Depending on the unit chosen here, the numerical format (number of
decimal places) shown in the RUN mode varies. When you modify it,
carefully take into account the count capacity and the number of
decimal places to be shown.
