Oval EL4101 - ① Viscosity Compensation (Μ) - Unit Setup (UNIT); ② Viscosity Compensation (Μ) - under Alarm Point Setup (under ALARM POINT)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＶＩＳＣＯＳＩＴＹ ＣＯＭＰ．（μ） 


ＵＮＩＴ               
                   ｃＰ

１：Ｐ              
 ２：ｃＰ               
 ３：Ｐａ・ｓ             
 ４：ｍＰａ・ｓ          
 ５：Ｎ・ｓ／ｍ２            
                     
                     
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＶＩＳＣＯＳＩＴＹ ＣＯＭＰ．（μ）  


ＵＮＤＥＲ ＡＬＡＲＭ ＰＯＩＮＴ  
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
↑−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＶＩＳＣＯＳＩＴＹ ＣＯＭＰ．（μ）

・μ２               
         ＋１．０００００ Ｅ＋０
 ・μ３  
         ＋２．０００００ Ｅ＋０
 ・ＦＲＥＱＵＥＮＣＹ１         
         ＋０．０００００ Ｅ＋０
 ・ＥＲＲＯＲ１１            
         ＋０．０００００ Ｅ＋０

↓−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ 
E-880TM-3-E
13
⑥ Viscosity comp. (μ) - viscosity μ2 setup (μ2) p. 136
⑦ Viscosity comp. (μ) - viscosity μ3 setup (μ3) p. 137
⑧ Viscosity comp. (μ) - freq. setup 1 to 9 (FREQUENCY 1 to 9) p. 137
⑨ Viscosity comp. (μ) - meter error setup 11 to 93 (ERROR 11 to 93) p. 137
To the setup screen pointed by the cursor
SET mode main menu screen ⇒ 6.2 SET mode main menu screen p. 36
① Viscosity compensation (μ) - unit setup (UNIT)
Viscosity unit is selected here.
Viscosity compensation ( μ )
submenu screen p. 134
② Viscosity compensation (μ) - under alarm point setup (UNDER ALARM POINT)
The under alarm point of viscosity to be set in the parameter setup mode is set up here.
Viscosity compensation ( μ ) submenu screen p. 134
Unit Number of decimal places
P
3
cP
1
Pa ･ s
4
mPa ･ s 1
N ･ s/m
2
4
Number of decimal places for
each unit
←Unit option select
For details of option setup, see “(2) Option select setup screen (SELECT)” on
page 46. The unit you can choose from are.“P”, “cP”, “Pa・s”, “mPa・s”, and
or “N・s/m
2
”.
※ As the measurement unit is changed, current parameters are converted
automatically to read in the new measurement unit chosen.
※ The unit to be set here is the measuring unit set at the viscosity setup and
displayed in the RUN mode, that of the viscosity to be set at the viscosity
setup screen in the SET mode, and the viscosity unit to be set in the
PARA SET mode. Modifying this unit will change the viscosity set and
displayed in the RUN mode and the viscosity unit to be set in the PARA
SET mode (① Vicosity unit setup (UNIT) on page 181) also to read in the
same unit modified.
※ Depending on the unit chosen here, the numerical format (number of
decimal places) of the set viscosity displayed in the RUN mode varies.
When you modify it, carefully take into account the count capacity and
the number of decimal places to be shown.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ For the unit to be set here, the unit set at the unit setup of viscosity
compensation (① Viscosity compensation (μ) unit setup (UNIT) on page
135) is used. Make sure of the unit before you set up.
