Oval EL4101 - ② Pulse Output Width Setup (PULSE WIDTH)

                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

ＰＵＬＳＥ ＯＵＴＰＵＴ        


ＰＵＬＳＥ ＷＩＤＴＨ        
                  １ｍＳ
 １：１ｍＳ              

２：５０ｍＳ     
                     
                     
                     
                     
                     
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
E-880TM-3-E
18
Model
Output
Options
EL4101
PULSE OUTPUT1 to 3
“NONE”, “TOTAL COUNT 1” (corrected mass total)
“TOTAL COUNT 2” (corrected thermal total), “ALARM” (alarm output)
EL4111
“NONE”, “TOTAL COUNT 1” (corrected mass total)
“TOTAL COUNT 2” (corrected thermal total), “ALARM” (alarm output)
EL4121
“NONE”, “TOTAL COUNT” (uncorrected total)
“TOTAL COUNT (C)” (corrected total), “ALARM” (alarm output)
EL4131
“NONE”, “TOTAL COUNT” (uncorrected total)
“TOTAL COUNT (C)” (corrected total), “ALARM” (alarm output)
EL4201
“NONE”, “TOTAL COUNT 1” (uncorrected total)
“TOTAL COUNT 2” (corrected mass total), “ALARM” (alarm output)
EL4211
“NONE”, “TOTAL COUNT 1” (uncorrected total)
“TOTAL COUNT 2” (corrected mass total), “ALARM” (alarm output)
EL4301 PULSE OUTPUT3 “NONE”, “ALARM” (alarm output)
EL4311
PULSE OUTPUT1 to 3
“NONE”, “TOTAL COUNT 1” (corrected mass total)
“TOTAL COUNT 2” (corrected mass solids content total),
“ALARM” (alarm output)
EL4321
“NONE”, “ALARM” (alarm output)
EL4401
“NONE”, “TOTAL COUNT 1” (corrected total)
“TOTAL COUNT 2” (corrected mass total), “ALARM” (alarm output)
EL4501
“NONE”, “ALARM” (alarm output), “TOTAL COUNT 1” (uncorrected total),
“TOTAL COUNT 2” (viscosity corrected total),
“TOTAL COUNT 3” (visc./temp. corrected total)
EL4511
“NONE”, “ALARM” (alarm output), “TOTAL COUNT 1” (uncorrected total),
“TOTAL COUNT 2” (viscosity corrected total),
“TOTAL COUNT 3” (visc./temp. corrected total)
・Avaiable options
※ “ALARM” (alarm output) is a status output to be produced when at least one error occurred.
※ This item is not shown in models other than above.
Pulse output submenu
screen p. 157
② Pulse output width setup (PULSE WIDTH)
The pulse width of output is set up here.
←Output type option select
For details of option setup, see “(2) Option select setup screen (SELECT)” on
page 46.
※ At pulse output 3, this item is not shown. The pulse output width of pulse
output 3 is set up with a jumper.
※ If 50ms is selected for pulse output width, great care should be taken in
the proper selection of output pulse frequency. With 50ms selected,
proper output will not be produced above 20Hz in the pulse output
frequency. So, in an application where the output pulse frequency
exceeds 20Hz, select a greater scaling factor for the pulse output to have
a larger unit of the output pulse, or select a width of 1ms. (With a 50ms
width selected, as a rule of thumb, the maximum frequency of pulse
output is 10Hz.)
