Oval EL4101 - ② Pressure Input Constant Setup (CONSTANT); ③ Pressure Input Baseline Setup (BASE SCALE); ④ Pressure Input Full Scale Setup (FULL SCALE)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＰＲＥＳＳ． ＩＮＰＵＴ        


ＦＵＬＬ ＳＣＡＬＥ        
         ＋１．０００００ Ｅ＋１
                     
                     
                     
＋１．０００００  
       Ｅ＋１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＰＲＥＳＳ． ＩＮＰＵＴ        


ＣＯＮＳＴＡＮＴ         
          ＋１．０００００Ｅ＋０
                     
                     
                     
＋１．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＰＲＥＳＳ． ＩＮＰＵＴ        


ＢＡＳＥ ＳＣＡＬＥ        
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
E-880TM-3-E
8
② Pressure input constant setup (CONSTANT)
In the SYS mode, when the input type is set to NONE, constants are set.
※ Constants are fixed values set internally in the equipment contrary to the measurements of
external input.
To press. input submenu screen p. 56
③ Pressure input baseline setup (BASE SCALE)
The baseline value with respect to the pressure input is set up here.
④ Pressure input full scale setup (FULL SCALE)
The full scale value with respect to the pressure input is set up here.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown unless the pressure input type
(① Pressure input type setup (TYPE) on page 155) is set to”NONE”.
※ For the unit to be set here, the unit set at the pressure input unit setup
(① Pressure input unit setup (UNIT) on page 57) is used. Make sure of the
unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown unless the pressure input type
(① Pressure input type setup (TYPE) on page 155) is set to”NONE”.
※ For the unit to be set here, the unit set at the pressure input unit setup
(① Pressure input unit setup (UNIT) on page 57) is used. Make sure of the
unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown unless the pressure input type
(① Pressure input type setup (TYPE) on page 165) is set to”NONE”.
※ For the unit to be set here, the unit set at the pressure input unit setup
(① Pressure input unit setup (UNIT) on page 57) is used. Make sure of the
unit before you set up.
To press. input submenu screen p. 56
To press. input submenu screen p. 56
