Oval EL4101 - Pressure Input Setup (PRESS. INPUT); Pressure Input Submenu Screen; ① Pressure Input Type Setup (TYPE)

                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

ＰＲＥＳＳ． ＩＮＰＵＴ        


ＴＹＰＥ               
                 １−５Ｖ
 １：ＮＯＮＥ              

２：４−２０ｍＡ            
 ３：１−５Ｖ              
                     
                     
                     
                     
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ 
                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

ＰＲＥＳＳ． ＩＮＰＵＴ        

・ＴＹＰＥ               
                 １−５Ｖ
                     
                     
                     
                     
                     
                     
                     
−−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ 
E-880TM-3-E
1
7.4.5 Pressure Input Setup (PRESS. INPUT)
The type of input for the pressure input is set up here.
（1）Pressure input submenu screen
At the submenu, move the cursor to the desire setup item with the up and down arrow keys.
At the touch of function key “ENTR”, the screen switches to the desired setup screen.
① Pressure input type setup (TYPE) on page 155
Pressure input submenu screen p. 156
To the setup screen pointed by the cursor
7.1.1 SYS mode main menu screen p. 142
① Pressure input type setup (TYPE)
The type of input for the pressure input is set up here.
Model Options
EL4101
“NONE”, “4 to 20mA”, “1 to 5V”
EL4111
“NONE”, “4 to 20mA”, “1 to 5V”
EL4121
“NONE”, “4 to 20mA”, “1 to 5V”
EL4201
“NONE”, “4 to 20mA”, “1 to 5V”
EL4321
“NONE”, “4 to 20mA”, “1 to 5V”
・Available items for setup
※ This item is not shown in models other than above.
←Input type option setup
For details of option setup, see “(2) Option select setup screen (SELECT)” on
page 46.
※ In cases where the user has changed the input type to NONE (constant)
or to other type, do not fail to set up the constant at the pressuare input
setup in the SET mode (② Pressure input constant setup (CONSTANT) on
page 58), and set up the pulse output scaling (Section 6.4.27 Pulse output
scaling setup (PULSE OUT DIVIDE) on page 138). Unless they are so
configured, the computer possibly may not perform properly.
