Oval EL4101 - ① Analog Output Unit Setup (UNIT)

                     
／                    
↑−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＡＮＡＬＯＧ ＯＵＴＰＵＴ      

・ＬＯＷ ＬＩＭＩＴ（ｍＡ）      
         ＋４．０００００ Ｅ＋０
 ・ＬＯＷ ＣＵＴ            
         ＋０．０００００ Ｅ＋０
 ・ＳＭＯＯＴＨＩＮＧ ＣＯＥＦ．
         ＋８．７５０００ Ｅ−１
                     
           
            
−−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＡＮＡＬＯＧ ＯＵＴＰＵＴ       


ＵＮＩＴ               
                 ｍ３／ｈ

１：ｋｌ／ｈ              
 ２：Ｋｌ／ｍｉｎ            
 ３：ｌ／ｈ               
 ４：ｌ／ｍｉｎ             
 ５：ｍｌ／ｈ              
 ６：ｍｌ／ｍｉｎ            
 ７：ｍ３／ｈ              
↓−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
E-880TM-3-E

⑤ Analog output low limit setup (LOW LIMIT (mA)) p. 79
⑥ Analog output low cutoff setup (LOW CUT) p. 79 ※1
⑦ Analog output smoothing factor setup (SMOOTHING COEF.) p. 79
To the setup screen pointed by the cursor
SET mode main menu screen ⇒ 6.2 SET mode main menu screen p. 36
※
Not shown except for Model EL4401
① Analog output unit setup (UNIT)
Analog output measurement unit is selected here.
Analog output submenu screen p. 76
Model Available measurement unit options Analog output options (SYS mode)
EL4101 kg/h, kg/min, g/h, g/min, t/h, t/min, lb/h, lb/min Instant mass flowrate (fixed ※ 1)
EL4111 kg/h, kg/min, g/h, g/min, t/h, t/min, lb/h, lb/min Instant mass flowrate (fixed ※ 1)
EL4121
kl/h, kl/min, l/h, l/min, ml/h, ml/min, m
3
/h, m
3
/min,
kl/h(std), kl/min(std), l/h(std), l/min(std), ml/h(std), ml/min(std),
m
3
/h(std), m
3
/min(std), kl/h(nor), kl/min(nor), l/h(nor),
l/min(nor), ml/h(nor), ml/min(nor), m
3
/h(nor), m
3
/min(nor)
Instant flowrate, before and after
correction
EL4131
kl/h, kl/min, l/h, l/min, ml/h, ml/min, m
3
/h, m
3
/min, kl/h(C),
kl/min(C), l/h(C), l/min(C), ml/h(C), ml/min(C), m
3
/h(C), m
3
/min(C)
Instant flowrate, before and after
correction
EL4201
kl/h、kl/min、l/h、l/min、ml/h、ml/min、m
3
/h、m
3
/min、kg/h、
kg/min、g/h、g/min、t/h、t/min、lb/h、lb/min
Instant flowrate, before and after
correction
EL4211
kl/h, kl/min, l/h, l/min, ml/h, ml/min, m
3
/h, m
3
/min, kg/h,
kg/min, g/h, g/min, t/h, t/min, lb/h, lb/min
Instant flowrate, before and after
correction
EL4301 g/ml, g/l, kg/ml, kg/l, ％ Corrected density, solids content (% mass)
EL4311
kg/h, kg/min, g/h, g/min, t/h, t/min, lb/h, lb/min, ％ , g/ml,
g/l, kg/ml, kg/l
Instant mass flowrate, instant solids content flowrate,
solids content (% mass), corrected density
EL4321 g/ml, g/l, kg/ml, kg/l Corrected instant flowrate (fixed ※ 1)
EL4401
kl/h, kl/min, l/h, l/min, ml/h, ml/min, m
3
/h, m
3
/min,
kl/h(std), kl/min(std), l/h(std), l/min(std), ml/h(std), ml/min(std),
m
3
/h(std), m
3
/min(std), kl/h(nor), kl/min(nor), l/h(nor),
l/min(nor), ml/h(nor), ml/min(nor), m
3
/h(nor), m
3
/min(nor)
Corrected Instant flowrate (fixed ※ 1)
EL4501 ℃ , °Ｆ , Ｋ Temperature (fixed ※ 1)
EL4511 ℃ , °Ｆ , Ｋ Temperature (fixed ※ 1)
Available measurement units
※１：
Because the output is fixed, setup items of analog output are not shown in the SYS mode.
←Numerical value input setup
For details of selecting options setup, see “(2) Option select setup screen
(SELECT)” on page 46.
※ On-screen options vary from model to model.
※ As the measurement unit is changed, current parameters (baseline, full
scale setpoint, etc.) are converted automatically to read in the new
measurement unit chosen.
