Oval EL4101 - Superheated Steam Specific Enthalpy Setup (SPEC. ENTHALPY (SUP)); Superheated Steam Specific Enthalpy Submenu Screen; ① Superheated Steam Specific Enthalpy Unit Setup (UNIT)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＳＰＥＣ． ＥＮＴＨＡＬＰＹ（ＳＵＰ） 


ＵＮＩＴ               
              ｋｃａｌ／ｋｇ

１：ｋＪ／ｋｇ             
 ２：Ｊ／ｇ               
 ３：ｋｃａｌ／ｋｇ           
 ４：ｃａｌ／ｇ             
                     
                     
                     
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＳＰＥＣ． ＥＮＴＨＡＬＰＹ（ＳＵＰ） 

・ＵＮＩＴ               
              ｋｃａｌ／ｋｇ
                     
                     
                     
                     
                     
                     
                     
−−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ 
E-880TM-3-E

6.4.16 Superheated Steam Specific Enthalpy Setup (SPEC. ENTHALPY (SUP))
As the parameters associated with the specific ethalpy of superheated steam, their measurement units
are set up here.
※ The units to be set here are on-screen units in the RUN mode, and they by no means affect
calculation and other settings.
＜Calculation Formula＞
where ａ, ｂ：Coefficients for temperature
a＝α
1
＋β
1
・P＋γ
1
・P
2
、 b＝α
2
＋β・P＋γ
2
・P
2
Ｔ：Temperature（℃）
Ｐ：Abs. pressure（Ｐ＝Ｐ’+0.101325）
Ｐ’： Line pressure（MPa）
α, β, γ：Coefficients for pressure
（1）Superheated steam specific enthalpy submenu screen
At the submenu, move the cursor to the desired setup item with the up and down arrow keys.
At the touch of function key “ENTR”, the screen switches to the desired item setup screen.
① Superheated steam specific enthalpy unit setup (UNIT) p. 94
To the setup screen pointed by the cursor
SET mode main menu screen ⇒ 6.2 SET mode main menu screen p. 36
K＝ a＋bT
Unit Number of decimal places
kJ/kg
2
J/g
2
kcal/kg 3
cal/g
3
Number of decimal places for each unit
① Superheated steam density unit setup (UNIT)
The unit for superheated steam specific enthalpy calculation is set up here.
Superheated steam specific enthalpy submenu screen
←Unit option select setup
For details of option setup, see “(2) Option select setup screen (SELECT)” on
page 46.
The unit you can choose from are “kJ/kg”, “J/g”, “kcal/kg”, and or “cal/g”.
※ The unit to be set is that of the specific enthalpy displayed in the RUN mode.
※ Depending on the unit chosen here, the numerical format (number of
decimal places) of specific enthalpy shown in the RUN mode varies.
When you modify it, carefully take into account the count capacity and
the number of decimal places to be shown.
