Oval EL4101 - EL4111 Steam Service Flow Computer (Superheated Steam Service)

                     
／                    
ＴＯＴＡＬ ＣＯＵＮＴ１      １／４
       １２３
             ０．０１  kｇ
ＴＯＴＡＬ ＣＯＵＮＴ２ 
      １２３４
            ０．１ 
ＦＬＯＷ ＲＡＴＥ            
         ０
                 kｇ／ｈ
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜     
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜    
                     
／                    
ＴＥＭＰＥＲＡＴＵＲ        ２／４
    １５０．００
                   ゜Ｃ
ＰＲＥＳＳＵＲＥ       
    ０．００００
                  ＭＰａ


             
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
ＣＯＭＰ．ＦＡＣＴＯＲ１      ３／４
   ０．００１０４
                     
ＣＯＭＰ. ＦＡＣＴＯＲ２   
    ０．６８７０
                     
ＭＥＴＥＲ ＥＲＲＯＲ          
   １．０００００
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
ＭＥＴＥＲ ＣＯＥＦ．       ４／４
   １．０００００
                     
ＳＰＥＣ． ＷＥＩＧＨＴ（ＳＵＰ）
    １．０３９１
                ｋｇ／ｍ３
ＳＰＥＣ． ＥＮＴＨＡＬＰＹ（ＳＵＰ）  
    ６６１．１１
              k J／ｋｇ 
 ＭＯＤＥ｜ＥＲＲ．｜    ｜ＰＡＧＥ
 ＭＥＮＵ｜ＬＯＧ．｜    ｜ＤＯＷＮ
k J
E-880TM-3-E

5.4.2 EL4111 Steam Service Flow Computer (superheated steam service)
←RUN mode screen 1
Pressing function key “PAGE UP” switches the screen to the next screen.
“TOTAL COUNT 1”: Corrected total mass flowrate
“TOTAL COUNT 2”: Corrected total heat quantity flow
“FLOW RATE”: Corrected instant mass flowrate
※ Measurement units, exponent, and indicated values vary with actual
settings (SET mode).
←RUN mode screen 2
Pressing (the) function key “PAGE UP” switches the screen to the next screen;
pressing (the) function key “PAGE DOWN” switches the screen to the previous
screen.
“TEMPERATURE”: Temperature
“PRESSURE”: Pressure
※The placement of decimal point in temperature or pressure reading varies
with the measurement unit selected. (For the decimal point of pressure,
see “① Temperature input unit setup (UNIT)” on page 51. For the decimal
point of pressure, see “① Pressure unit setup (UNIT)” on page 57.)
←RUN mode screen 3
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing function key “PAGE DOWN” switches the screen to the previous screen.
“COMP. FACTOR 1”: Correction factor 1 = Meter error corr. factor×3α×relative
density
“COMP. FACTOR 2”: Correction factor 2 = Meter error corr. factor×3α×relative
density × sp. enthalpy
“METER ERROR”: Meter error correction factor
←RUN mode screen 4
Pressing function key “PAGE DOWN” switches the screen to the previous screen.
“METER COEF.”: Meter correction factor
“SPEC. WEIGHT (SAT)”: Relative density (specific weight)
“SPEC. ENTHALPY (SAT)”: Specific enthalpy
※ The placement of decimal point in relative density (sp. weight) and
specific enthalpy readings varies with the measurement units selected.
(For the decimal point of relative density (sp. weight), see “① Superheated
steam density unit setup (UNIT)” on page 92. For the decimal point of
specific enthalpy, see “① Superheated steam specific enthalpy unit setup
(UNIT)” on page 94.)
