Oval EL4101 - ③ Temperature Input Baseline Setup (BASE SCALE); ④ Temperature Input Full Scale Setup (FULL SCALE); ⑤ Temperature Input under Alarm Point Setup (under ALARM POINT)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＴＥＭＰ． ＩＮＰＵＴ         


ＢＡＳＥ ＳＣＡＬＥ         
         −５．０００００ Ｅ＋１
                     
                     
                     
＋５．０００００  
       Ｅ＋１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＴＥＭＰ． ＩＮＰＵＴ         


ＦＵＬＬ ＳＣＡＬＥ        
         ＋３．５００００ Ｅ＋２
                     
                     
                     
＋３．５００００  
       Ｅ＋２
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＴＥＭＰ． ＩＮＰＵＴ         


ＵＮＤＥＲ ＡＬＡＲＭ ＰＯＩＮＴ  
         −５．０００００ Ｅ＋１
                     
                     
                     
−５．０００００  
       Ｅ＋１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
E-880TM-3-E

③ Temperature input baseline setup (BASE SCALE)
The baseline with respect to the temperature input is set up here.
④ Temperature input full scale setup (FULL SCALE)
The full scale setpoint with respect to the temperature input is set up here.
To temp. input submenu screen p. 50
⑤ Temperature input under alarm point setup (UNDER ALARM POINT)
The under alarm point with respect to the temperature input is set up here.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown if the temperature input type
(① temperature input type setup (TYPE) on page 154) is set to “NONE”.
※ For the unit to be set here, the unit set at the temperature input unit setup
(① Temperature input unit setup (UNIT) on page 51) is used. Make sure of
the unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown if the temperature input type
(① temperature input type setup (TYPE) on page 154) is set to “NONE”.
※ For the unit to be set here, the unit set at the temperature input unit setup
(① Temperature input unit setup (UNIT) on page 51) is used. Make sure of
the unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown if the temperature input type
(① temperature input type setup (TYPE) on page 154) is set to “NONE”.
※ For the unit to be set here, the unit set at the temperature input unit setup
(① Temperature input unit setup (UNIT) on page 51) is used. Make sure of
the unit before you set up.
To temp. input submenu screen p. 50
To temp. input submenu screen p. 50
