Oval EL4101 - On-Screen Information of Respective Models; EL4101 Steam Service Flow Computer (Saturated Steam Service)

                     
／                    
ＴＯＴＡＬ ＣＯＵＮＴ１      １／４
       １２３
             ０．０１  ｋｇ
ＴＯＴＡＬ ＣＯＵＮＴ２ 
      １２３４
               １０  ｋＪ
                     
    
                     
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜     
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜    
                     
／                    
ＦＬＯＷ ＲＡＴＥ         ２／４
         ０
                 kｇ／ｈ
ＰＲＥＳＳＵＲＥ       
    ０．００００
                  ＭＰａ

    
        
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
ＣＯＭＰ． ＦＡＣＴＯＲ１     ３／４
   ０．０００６０
                     
ＣＯＭＰ． ＦＡＣＴＯＲ２   
    ０．３８４４
                     
ＭＥＴＥＲ ＥＲＲＯＲ          
   １．０００００
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
Ｅｔ                ４／４
   １．００３８４
                     
ＳＰＥＣ． ＷＥＩＧＨＴ（ＳＡＴ）
    ０．５９９０
                kｇ／ｍ３
ＳＰＥＣ． ＥＮＴＨＡＬＰＹ（ＳＡＴ）  
   ２６７６．２１
                ｋＪ／ｋｇ
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
E-880TM-3-E

5.4 On-screen Information of Respective Models
On-screen information in the RUN mode are described on the pages that follow.
5.4.1 EL4101 Steam Service Flow Computer (saturated steam service)
←RUN mode screen 1
Pressing function key “PAGE UP” switches the screen to the next screen.
“TOTAL COUNT 1”: Total (corrected mass) flow
“TOTAL COUNT 2”: Total (corrected heat quantity) flow
※ Measurement units, exponent, and indicated values vary with actual
settings (SET mode).
←RUN mode screen 2
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing function key “PAGE DOWN” switches the screen to the previous screen.
“FLOW RATE”: Instant (corrected mass) flowrate
“PRESSURE” : Pressure
※ The placement of decimal point in pressure reading varies with the
measurement unit selected. (For the decimal point of pressure, see
“① Pressure input unit setup (UNIT)” on page 57.)
←RUN mode screen 3
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing function key “PAGE DOWN” switches the screen to the previous screen.
“COMP. FACTOR 1”: Correction factor 1 = Meter error corr. factor×εt ×relative
density
“COMP. FACTOR 2”: Correction factor 2 = Meter error corr. factor×εt ×relative
density × sp. enthalpy
“METER ERROR”: Meter error correction factor
←RUN mode screen 4
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing function key “PAGE DOWN” switches the screen to the previous screen.
“Et.” Meter correction factor (εt)
“SPEC. WEIGHT (SAT)”: Relative density (specific weight)
“SPEC. ENTHALPY (SAT)”: Specific enthalpy
※ The placement of decimal point in relative density (sp. weight) and
specific enthalpy readings varies with the measurement units selected.
(For the decimal point of relative density (sp. weight), see “① Saturated
steam density unit setup (UNIT)” on page 91. For the decimal point of
specific enthalpy, see “① Saturated steam specific enthalpy unit setup
(UNIT)” on page 93.)
