8.3 Submenu Setup Items
8.3.1 Liquid A (B) Setup (FLUID A (B))
（1）Liquid A (B) setup submenu screen
At the submenu, move the cursor to the desired setup item with the up and down arrow keys.
At the touch of function key “ENTR”, the screen switches to the desired setup screen.
① Liquid A (B) - liquid kind setup (TYPE) p. 173
② Liquid A (B) - density unit setup (UNIT) p. 174
③ Liquid A (B) - density setup (DENSITY) p. 174
To the setup screen pointed by the cursor
7.1.1 SYS mode main menu screen p. 142
Liquid A (B) setup submenu screen p. 173
① Liquid A (B) - liquid kind setup (TYPE)
Liquid kind is set up here.
←Liqui A – submenu screen
If found out of range, an error message appears. The information the message
conveys are:
“SETTING OVERFLOW”: Density exceeds the high limit of range.
“SETTING UNDERFLOW”: Density falls below the low limit of range.
←Liquid kind option select
For details of option selection, see “(2) Option select setup screen (SELECT)” on
page 46.
Avaialble liquid kinds are “CRUDE OIL”, “FUEL”, and “LUBE”.
