Oval EL4101 - EL4121 Temperature;Pressure Compensated Flow Computer (Gas Service); EL4131 Liquid Temperature Compensated Flow Computer

                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＰＡＳＳＷＯＲＤ          
 ＊ＣＡＬＥＮＤAＲ           
 ＊ＳＩＭＵＬＡＴＥ           
 ＊ＴＥＭＰ． ＩＮＰＵＴ        
 ＊ＰＲＥＳＳ． ＩＮＰＵＴ       
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ１      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ２      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ３      
 ＊ＡＮＡＬＯＧ ＯＵＴＰＵＴ      
 ＊ＴＯＴＡＬ ＣＯＵＮＴ ＲＥＳＥＴ  
↓−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ
                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＰＡＳＳＷＯＲＤ          
 ＊ＣＡＬＥＮＤAＲ           
 ＊ＳＩＭＵＬＡＴＥ           
 ＊ＴＥＭＰ． ＩＮＰＵＴ        
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ１      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ２      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ３      
 ＊ＡＮＡＬＯＧ ＯＵＴＰＵＴ      
 ＊ＴＯＴＡＬ ＣＯＵＮＴ ＲＥＳＥＴ  
 ＊ＢＡＣＫＬＩＧＨＴ         
↓−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ
                     
                     
↑−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＢＡＣＫＬＩＧＨＴ         
 ＊ＲＵＮ ＰＡＧＥ  
 ＊ＣＯＭＭＵＮＩＣＡＴＩＯＮ






      
−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ 
                     
                     
↑−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＲＵＮ ＰＡＧＥ  
 ＊ＣＯＭＭＵＮＩＣＡＴＩＯＮ   







      
−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ 
E-880TM-3-E
1
7.3.3 EL4121 Temp./Press. Compensated Flow Computer (gas service)
7.3.4 EL4131 Liquid Temp. Compensated Flow Computer
＊PASSWPRD (password setup) p. 150
＊CALENDAR (calendar setup) p. 152
＊SIMULATE (analog output simulate) p. 153
＊TEMP. INPUT (temperatuare input setup) p. 154
＊PRESS. INPUT (pressure input setup) p. 155
＊PULSE OUTPUT 1 (pulse output 1 setup) p. 157
＊PULSE OUTPUT 2 (pulse output 2 setup) p. 157
＊PULSE OUTPUT 3 (pulse output 3 setup) p. 157
＊ANALOG OUTPUT (analog output setup) p. 159
＊TOTAL COUNT RESET (total counter reset setup) p. 160
＊BACKLIGHT (backlight setup) p. 161
＊RUN PAGE SAVE
(RUN mode page setup page shown in RUN mode save) p. 163
＊COMMUNICATION (communication setup)
※ model with com interface p. 166
＊PASSWPRD (password setup) p. 150
＊CALENDAR (calendar setup) p. 152
＊SIMULATE (analog output simulate) p. 153
＊TEMP. INPUT (temperatuare input setup) p. 154
＊PULSE OUTPUT 1 (pulse output 1 setup) p. 157
＊PULSE OUTPUT 2 (pulse output 2 setup) p. 157
＊PULSE OUTPUT 3 (pulse output 3 setup) p. 157
＊ANALOG OUTPUT (analog output setup) p. 159
＊TOTAL COUNT RESET (total counter reset setup) p. 160
＊BACKLIGHT (backlight setup) p. 161
＊RUN PAGE SAVE
(RUN mode page setup page shown in RUN mode save) p. 163
＊COMMUNICATION (communication setup)
※ model with com interface p. 166
