Oval EL4101 - EL4131 Liquid Temperature Compensated Flow Computer

                     
／                    
ＴＯＴＡＬ ＣＯＵＮＴ       １／３
       １２３
             ０．０１  ｍ３
ＴＯＴＡＬ ＣＯＵＮＴ（Ｃ） 
      １２３４
         ０．１  ｍ３（ｎｏｒ）
    
                     
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜     
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜    
                     
／                    
ＦＬＯＷ ＲＡＴＥ         ２／３
         ０
                 ｍ３／ｈ
ＦＬＯＷ ＲＡＴＥ（Ｃ）   
         ０
            ｍ３／ｈ（ｎｏｒ）
ＴＥＭＰＥＲＡＴＵＲＥ       
      ０．００
                   Ｃ 
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
ＭＥＴＥＲ ＥＲＲＯＲ       ３／３
   １．０００００
                     
ＴＥＭＰ． ＣＯＭＰＥＮ． 
   １．９６７８０
                     

   
            
 ＭＯＤＥ｜ＥＲＲ．｜    ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜    ｜ＤＯＷＮ
E-880TM-3-E
8
5.4.4 EL4131 Liquid Temperature Compensated Flow Computer
←RUN mode screen 1
Pressing function key “PAGE UP” switches the screen to the next screen.
“TOTAL COUNT”: Total flow
“TOTAL COUNT (C)”: Total (corrected) flow
※ Measurement units, exponent, and indicated values vary with actual
settings (SET mode).
←RUN mode screen 2
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing function key “PAGE DOWN” switches the screen to the previous screen.
“FLOW RATE”: Uncorrected instant flowrate
“FLOWRATE (C)”: Uncorrected instant flowrate
“TEMPERATURE”: Temperature
※ The placement of decimal point in temperature reading varies with the
measurement unit selected. (For the decimal point of temperature, see
“① Temperature input unit setup (UNIT)” on page 51.)
←RUN mode screen 3
Pressing (the) function key “PAGE UP” switches the screen to the next screen;
pressing (the) function key “PAGE DOWN” switches the screen to the previous
screen.
“METER ERROR”: Meter error correction factor
“TEMP. COMPEN.”: Temperature compensation
