Oval EL4101 - ① 3Α Correction Type Setup (TYPE); ② 3Α Correction Factor Α Setup (ALFA (Α)); ③ 3Α Correction Factor Β Setup (BETA (Β))

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

３α ＣＯＭＰＥＮ．         


ＡＬＦＡ（α）            
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

３α ＣＯＭＰＥＮ．         


ＴＹＰＥ               
                  α＝β

１：α＝β               
 ２：α󲰁β                
                     
                     
                     
                     
                     
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

３α ＣＯＭＰＥＮ．         


ＢＥＴＡ（β）            
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

３α ＣＯＭＰＥＮ．         


ＡＬＦＡ（α）            
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

３α ＣＯＭＰＥＮ．         


ＴＹＰＥ               
                  α＝β

１：α＝β               
 ２：α󲰁β                
                     
                     
                     
                     
                     
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

３α ＣＯＭＰＥＮ．         


ＢＥＴＡ（β）            
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
E-880TM-3-E
81
① 3α compensation - type setup (TYPE)
The 3α compensation type is set up here. Select either α = β or α ≠ β.
3 α correction submenu screen p. 80
② 3α compensation – coefficient α setup (ALFA (α))
Coefficient α (linear expansion coefficient of the meter body) is set up here.
③ 3α compensation – coefficient β setup (BETA (β))
When compensation type α ≠ β is selected, coefficient β (linear expansion coefficient of the bluff
body) is set up here.
←Correction type option select
For details of option setup, see “(2) Option select setup screen (SELECT)” on
page 46.
※ Reminder: Depending on the menu selected, the items on the submenu
vary.
3 α correction submenu screen p. 80
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SET mode, this item is not shown if the 3α compensation type
setup (① 3α compensation type setup (TYPE) on page 81) is set to
“α = β”.
※ If compensation type α = β is your option, value β is the same as value α.
3 α correction submenu screen p. 80
