Oval EL4101 - ⑦ Blend Input under Fallback Level Setup (under FALLBACK); ⑧ Blend Input over Fallback Level Setup (over FALLBACK); ⑨ Blend Input Smoothing Factor Setup (SMOOTHING COEF.)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ        


ＵＮＤＥＲ ＦＡＬＬＢＡＣＫ    
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ        


ＯＶＥＲ ＦＡＬＬＢＡＣＫ   
         ＋８．５００００ Ｅ＋１
                     
                     
                     
＋８．５００００  
       Ｅ＋１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ     


ＳＭＯＯＴＨＩＮＧ ＣＯＥＦ．   
         ＋５．０００００ Ｅ−１
                     
                     
                     
＋５．０００００  
       Ｅ−１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ        


ＵＮＤＥＲ ＦＡＬＬＢＡＣＫ    
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ        


ＯＶＥＲ ＦＡＬＬＢＡＣＫ   
         ＋８．５００００ Ｅ＋１
                     
                     
                     
＋８．５００００  
       Ｅ＋１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ     


ＳＭＯＯＴＨＩＮＧ ＣＯＥＦ．   
         ＋５．０００００ Ｅ−１
                     
                     
                     
＋５．０００００  
       Ｅ−１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
E-880TM-3-E

⑨ Blend input smoothing factor setup (SMOOTHING COEF.)
The smoothing factor with respect to the blend input is set up here.
Smoothing factor K=1－
Blend input submenu screen p. 62
Blend input submenu screen p. 62
Blend input submenu screen p. 62
1
Time constant（s）
※ Time constant is the time required for the indicated reading to reach 63% of the final level;
it reaches 86% after in twice the time duration of time constant and 95% in three times the time
duration of time constant.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ I n the SYS mode, this item is not shown if the blend input type
(① Blend input type setup (TYPE) on page 165) is set to “NONE”.
※ For the unit to be set here, the unit set at the blend input unit setup
(① Blend input unit setup (UNIT) on page 63) is used. Make sure of the
unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ I n the SYS mode, this item is not shown if the blend input type
(① Blend input type setup (TYPE) on page 165) is set to “NONE”.
※ For the unit to be set here, the unit set at the blend input unit setup
(① Blend input unit setup (UNIT) on page 63) is used. Make sure of the
unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ I n the SYS mode, this item is not shown if the blend input type
(① Blend input type setup (TYPE) on page 165) is set to “NONE”.
※ Do not enter a negative value in the integer part of setting, or it will cause
erratic operation.
⑦ Blend input under fallback level setup (UNDER FALLBACK)
The under fallback level with respect to the blend input is set up here.
⑧ Blend input over fallback level setup (OVER FALLBACK)
The over fallback level with respect to the blend input is set up here.
