Oval EL4101 - ④ Blend Input Full Scale Setup (FULL SCALE); ⑤ Blend Input under Alarm Point Setup (under ALARM POINT); ⑥ Blend Input over Alarm Point Setup (over ALARM POINT)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ        


ＦＵＬＬ ＳＣＡＬＥ        
         ＋１．０００００ Ｅ＋２
                    
                    
                    
＋１．０００００  
       Ｅ＋２
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ        


ＵＮＤＥＲ ＡＬＡＲＭ ＰＯＩＮＴ  
         ＋２．５００００ Ｅ＋１
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ        


ＯＶＥＲ ＡＬＡＲＭ ＰＯＩＮＴ   
         ＋１．０００００ Ｅ＋２
                     
                     
                     
＋１．０００００  
       Ｅ＋２
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
E-880TM-3-E

④ Blend input full scale setup (FULL SCALE)
The full scale value with respect to the blend input is set up here.
Blend input submenu screen p. 62
⑤ Blend input under alarm point setup (UNDER ALARM POINT)
The under alarm point with respect to the blend input is set up here.
Blend input submenu screen p. 62
⑥ Blend input over alarm point setup (OVER ALARM POINT)
The over alarm point with respect to the blend input is set up here.
Blend input submenu screen p. 62
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown if the blend input type
(① Blend input type setup (TYPE) on page 165) is set to “NONE”.
※ For the unit to be set here, the unit set at the blend input unit setup
(① Blend input unit setup (UNIT) on page 63) is used. Make sure of the
unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown if the blend input type
(① Blend input type setup (TYPE) on page 165) is set to “NONE”.
※ For the unit to be set here, the unit set at the blend input unit setup
(① Blend input unit setup (UNIT) on page 63) is used. Make sure of the
unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown if the blend input type
(① Blend input type setup (TYPE) on page 165) is set to “NONE”.
※ For the unit to be set here, the unit set at the blend input unit setup
(① Blend input unit setup (UNIT) on page 63) is used. Make sure of the
unit before you set up.
