Oval EL4101 - Density Pulse Input (DENS. PULSE INPUT); Density Pulse Input Submenu Screen; ① Density Pulse Input Unit Setup (UNIT)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳ．ＰＵＬＳＥ ＩＮＰＵＴ    


ＵＮＩＴ               
                   μｓ

１：μｓ             
 ２：ｍｓ             
                     
                     
                     
                     
                     
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳ．ＰＵＬＳＥ ＩＮＰＵＴ    

・ＵＮＩＴ               
                   μｓ
 ・ＲＥＦ．ＯＳＣＩＬＬＡＴＯＲ     
         ＋０．０００００ Ｅ＋０
                     
                     
                     
                     
                     
−−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ
E-880TM-3-E

6.4.6 Density Pulse Input (DENS. PULSE INPUT)
As the parameters associated with density pulse input, the measurement unit and correction factor for the
reference oscillator are set up here.
※ These settings are used in Models EL4301, EL4311, and EL4321. They are not used in other
models.
（1）Density pulse input submenu screen
At the submenu, move the cursor to the desired setup item with the up arrow and down arrow keys.
At the touch of function key “ENTR”, the screen switches to the item desired for reconfiguration.
① Density pulse input unit setup (UNIT) p. 72
② Density pulse input unit - internal reference oscillator corr. factor
(REF. OSCILLATOR) p. 73
To the setup screen pointed by the cursor
SET mode main menu screen ⇒ 6.2 SET mode main menu screen p. 36
① Density pulse input unit setup (UNIT)
The unit in the density period display and that at the density period setup of density input is set up
here.
Density pulse input submenu
screen p. 72
Unit Number of decimal places
μ s
2
ms
5
Number of decimal places in respective units
←Unit option select
For details of selecting options setup, see “(2) Option select setup screen
(SELECT)” on page 46.
The units that can be selected are “μs” and “ms”, and are common to all models.
※ As the measurement unit is changed, the values that read in this unit (e.g.,
density period with water) are converted automatically to read in the new
measurement unit chosen.
※ The unit to be set here is that of the density period displayed in the RUN
mode and of the density period to be set in the density calculation in the
SET mode.
※ Depending on the unit chosen here, the numerical format (number of
decimal places) shown in the RUN mode varies. When you modify it,
carefully take into account the count capacity and the number of decimal
places to be shown.
