Oval EL4101 - SYS Mode Menu Tree; EL4101 Steam Service Flow Computer (Saturated Steam Service); EL4111 Steam Service Flow Computer (Superheated Steam Service)

                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＰＡＳＳＷＯＲＤ          
 ＊ＣＡＬＥＮＤAＲ           
 ＊ＳＩＭＵＬＡＴＥ           
 ＊ＰＲＥＳＳ． ＩＮＰＵＴ       
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ１      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ２      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ３      
 ＊ＴＯＴＡＬ ＣＯＵＮＴ ＲＥＳＥＴ  
 ＊ＢＡＣＫＬＩＧＨＴ         
 ＊ＲＵＮ ＰＡＧＥ  
↓−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ
                     
                     
↑−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＲＵＮ ＰＡＧＥ  
 ＊ＣＯＭＭＵＮＩＣＡＴＩＯＮ   







      
−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ 
                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＰＡＳＳＷＯＲＤ          
 ＊ＣＡＬＥＮＤAＲ           
 ＊ＳＩＭＵＬＡＴＥ           
 ＊ＴＥＭＰ． ＩＮＰＵＴ        
 ＊ＰＲＥＳＳ． ＩＮＰＵＴ       
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ１      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ２      
 ＊ＰＵＬＳＥ ＯＵＴＰＵＴ２      
 ＊ＴＯＴＡＬ ＣＯＵＮＴ ＲＥＳＥＴ  
 ＊ＢＡＣＫＬＩＧＨＴ         
↓−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ 
                     
                     
↑−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

＊ＣＯＭＭＵＮＩＣＡＴＩＯＮ   








      
−−−−−＜ＭＡＩＮ ＭＥＮＵ＞−−−−−
     ｜    ｜    ｜     
 ＥＸＩＴ｜    ｜    ｜ＥＮＴＲ 
E-880TM-3-E
1
7.3 SYS Mode Menu Tree
System mode menus differ from model to model as shown below.
7.3.1 EL4101 Steam Service Flow Computer (sataurated steam service)
7.3.2 EL4111 Steam Service Flow Computer (superheated steam service)
＊PASSWPRD (password setup) p. 150
＊CALENDAR (calendar setup) p. 152
＊SIMULATE (analog output simulate) p. 153
＊PRESS. INPUT (pressure input setup) p. 155
＊PULSE OUTPUT 1 (pulse output 1 setup) p. 157
＊PULSE OUTPUT 2 (pulse output 2 setup) p. 157
＊PULSE OUTPUT 3 (pulse output 3 setup) p. 157
＊TOTAL COUNT RESET (total counter reset setup) p. 160
＊BACKLIGHT (backlight setup) p. 161
＊RUN PAGE SAVE (RUN mode page setup save) p. 163
＊COMMUNICATION (communication setup)
※ model with com interface p. 166
＊PASSWPRD (password setup) p. 150
＊CALENDAR (calendar setup) p. 152
＊SIMULATE (analog output simulate) p. 153
＊TEMP. INPUT (temperatuare input setup) p. 154
＊PRESS. INPUT (pressure input setup) p. 155
＊PULSE OUTPUT 1 (pulse output 1 setup) p. 157
＊PULSE OUTPUT 2 (pulse output 2 setup) p. 157
＊PULSE OUTPUT 3 (pulse output 3 setup) p. 157
＊TOTAL COUNT RESET (total counter reset setup) p. 160
＊BACKLIGHT (backlight setup) p. 161
＊RUN PAGE SAVE (RUN mode page setup save) p. 163
＊COMMUNICATION (communication setup)
※ model with com interface p. 166
