Oval EL4101 - ⑫ Density Calculation - Water Temperature During Calibration (WATER TEMP.); ⑬ Density Calculation - Density Period with Water (WATER PERIOD); ⑭ Density Calculation - Temp. Corr. Coeff. of Tube Spring Constant (COEFFICIENT (Α))

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＣＯＥＦＦＣＩＥＮＴ α       
         ＋４．４４０００ Ｅ−４
                     
                     
                     
＋４．４４０００  
       Ｅ−４
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＷＡＴＥＲ ＰＥＲＩＯＤ       
         ＋１．３２３４６ Ｅ＋４
                     
                     
                     
＋１．３２３４６  
       Ｅ＋４
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＷＡＴＥＲ ＴＥＭＰ．        
         ＋１．８００００ Ｅ＋１
                     
                     
                     
＋１．８００００  
       Ｅ＋１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
E-880TM-3-E
118
⑫ Density calculation - water temperature during calibration (WATER TEMP.)
The water temperature is set up here for densicy calculation.
Density calculation setup submenu screen p. 112
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In SYS mode density input (① Density input type setup (TYPE) on page
156), if NONE is chosen for the input type, this menu will not be shown.
※ For the unit to be set here, the unit set at the temperature unit setup
(① Temperature input unit setup (UNIT) on page 51) is used. Make sure of
the unit before you set up.
⑬ Density calculation - density period with water (WATER PERIOD)
The density period with water is set up here for density calculation.
Density calculation setup submenu screen p. 112
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In SYS mode density input (① Density input type setup (TYPE) on page
156), if NONE is chosen for the input type, this menu will not be shown.
※ For the unit to be set here, the unit set at the density pulse unit setup
(① Density pulse input unit setup (UNIT) on page 72) is used. Make sure
of the unit before you set up.
⑭ Density calculation - temp. compensation coefficient for tube spring
constant (COEFFICIENT (α))
The thermal expansion coefficient of fluid is set up here for temperature compensation.
Density calculation setup submenu screen p. 112
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In SYS mode density input (① Density input type setup (TYPE) on page
156), if NONE is chosen for the input type, this menu will not be shown.
※ The unit of the value parameter to be set here is “%/°C”. Make sure of the
unit before you set up.
