Oval EL4101 - ② Density Calculation - Constants (CONSTANT); ③ Density Calculation - under Alarm Point Setup (under ALARM POINT); ④ Density Calculation - over Alarm Point Setup (over ALARM POINT)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＵＮＤＥＲ ＡＬＡＲＭ ＰＯＩＮＴ  
         ＋８．５００００ Ｅ＋２
                     
                     
                     
＋１．０００００  
       Ｅ−２
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＣＯＮＳＴＡＮＴ         
          ＋１．０００００Ｅ＋０
                     
                     
                     
＋１．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＯＶＥＲ ＡＬＡＲＭ ＰＯＩＮＴ   
         ＋２．０００００ Ｅ＋０
                     
                     
                     
＋２．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
E-880TM-3-E
1
② Density calculation - constants (CONSTANT)
In the density input in the SYS mode, when the input type is set to NONE, constants are set.
※ Constants are fixed values set internally in the equipment contrary to the measurements
entered through external input.
Density calculation submenu screen p. 123
③ Density calculation - under alarm point setup (UNDER ALARM POINT)
The under alarm point with respect to the corrected density is set up here.
Density calculation submenu screen p. 123
④ Density calculation - over alarm point setup (OVER ALARM POINT)
The over alarm point with respect to the corrected density is set established here.
Density calculation submenu screen p. 123
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the density input in the SYS mode (① Density input type setup (TYPE)
on page 156), this item is not shown unless the input type is set to NONE.
※ For the unit to be set here, the unit set at the density unit setup in density
calculation (① Density calculation unit setup (UNIT) on page 125) is used.
Make sure of the unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the density input in the SYS mode (① Density input type setup (TYPE)
on page 156), this item is not shown unless the input type is set to NONE.
※ For the unit to be set here, the unit set at the density unit setup in density
calculation (① Density calculation unit setup (UNIT) on page 125) is used.
Make sure of the unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the density input in the SYS mode (① Density input type setup (TYPE)
on page 156), this item is not shown unless the input type is set to NONE.
※ For the unit to be set here, the unit set at the density unit setup in density
calculation (① Density calculation unit setup (UNIT) on page 125) is used.
Make sure of the unit before you set up.
