Oval EL4101 - Density Setup (DENSITY); Density Setup Submenu Screen; ① Density Unit Setup (UNIT); ② Density Setup (DENSITY)

                     
                     
−−−−−＜ＰＡＲＡ ＳＥＴ＞−−−−−−

ＤＥＮＳＩＴＹ             


ＵＮＩＴ               
                kｇ／ｍ３
 １：kｇ／ｍ３        

２：ｇ／ｍｌ            
 ３：ｇ／ｌ                   
 ４：kｇ／ｍｌ                 
 ５：kｇ／ｌ                  
 ６：ｇ／ｃｍ３            
                     
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ 
                     
                     
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ          


ＤＥＮＳＩＴＹ            
          ＋１．５００００Ｅ＋１
                     
                     
                     
＋１．５００００  
       Ｅ＋１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
                     
−−−−−＜ＰＡＲＡ ＳＥＴ＞−−−−−−

ＤＥＮＳＩＴＹ             

・ＵＮＩＴ          
                kｇ／ｍ３
 ・ＤＥＮＳＩＴＹ            
         ＋１．０００００ Ｅ＋０
                     
                     
                     
                     
                     
−−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ
E-880TM-3-E
180
9.3.2 Density Setup (DENSITY)
（1）Density setup submenu screen
At the submenu, move the cursor to the desired setup item with the up and down arrow keys.
At the touch of function key “ENTR”, the screen switches to the desired setup screen.
① Density unit setup (UNIT) p. 180
② Density setup (UNIT) p. 180
To the setup screen pointed by the cursor
9.2.1 PARA SET mode main menu screen p. 176
Density setup submenu
screen p. 180
① Density unit setup (UNIT)
Density unit is selected here.
Density setup submenu screen p. 180
② Density setup (DENSITY)
Density is setup here.
←Unit option select
For details of option selection, see “(2) Option select setup screen (SELECT)” on
page 46.
Avaialble liquid kinds are “kg/m
3
”, “g/ml”, “g/l”, “kg/ml”, “kg/l” and “g/cm
3
”.
※ The unit to be set here is the unit of the density set and displayed in the
RUN mode, that of the density to be set at the density parameter setup in
the SET mode, and that of the density to be set in the PARA SET mode.
Modifying this unit results in modifying both the unit of the density set
and displayed in the RUN mode and that of the density to be set in the
SET mode (① Density parameter unit setup (UNIT) on page 130) to read in
the same unit.
※ Depending on the unit chosen here, the numerical format (number of
decimal places) shown in the RUN mode varies. When you modify it,
carefully take into account the count capacity and the number of decimal
places to be shown.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ For the unit to be set up here, the unit set up at the density unit setup (①
Density unit setup (UNIT) on page 180) is used. Make sure of the unit
before you set up.
                     
                     
