Oval EL4101 - ① Blend Input Unit Setup (UNIT); ② Blend Input Constant Setup (CONSTANT); ③ Blend Input Baseline Setup (BASE SCALE)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ        


ＵＮＩＴ               
                    ％

１：％            





                     
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ        


ＣＯＮＳＴＡＮＴ         
          ＋１．０００００Ｅ＋１
                     
                     
                     
＋１．０００００
       Ｅ＋１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＵＲＥＮＤ ＩＮＰＵＴ      


ＢＡＳＥ ＳＣＡＬＥ       
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ        


ＵＮＩＴ               
                    ％

１：％            





                     
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ        


ＣＯＮＳＴＡＮＴ         
          ＋１．０００００Ｅ＋１
                     
                     
                     
＋１．０００００
       Ｅ＋１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＵＲＥＮＤ ＩＮＰＵＴ      


ＢＡＳＥ ＳＣＡＬＥ       
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
E-880TM-3-E
3
① Blend input unit setup (UNIT)
Measurement unit of blend input is selected here.
Blend input submenu screen p. 62
② Blend input constants (CONSTANT)
In the SYS mode, when the input type is set to NONE, constants are set.
※ Constants are fixed values set internally in the equipment contrary to the measurements of
external input.
③ Blend input baseline setup (BASE SCALE)
The baseline value with respect to the blend input is set up here.
Unit Number of decimal places
％
2
Number of decimal places for each unit
←Unit option select
For details of measurement unit selection, see “(2) Measurement unit selection
(SELECT)” on page 46.
※ The unit to be set here is the blend unit displayed in the RUN mode and
the unit to be set by the blend input in the SET mode.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown unless the blend input type
(① Blend input type setup (TYPE) on page 165) is set to “NONE”.
※ For the unit to be set here, the unit set at the blend input unit setup
(① Blend input unit setup (UNIT) on page 63) is used. Make sure of the
unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown if the blend input type
(① blend input type setup (TYPE) on page 165) is set to “NONE”.
※ For the unit to be set here, the unit set at the blend input unit setup
(① Blend input unit setup (UNIT) on page 63) is used. Make sure of the
unit before you set up.
Blend input submenu screen p. 62
Blend input submenu screen p. 62
