Oval EL4101 - EL4321 Density Computer (Oscillating Spool Densitometer, Gas Service)

                     
／                    
ＤＥＮＳＩＴＹ           １／４
     ２．０００
                  ｇ／ｌ
ＤＥＮＳＩＴＹ（Ｃ）     
     ３．４１７
                  ｇ／ｌ
                     
    
                     
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜     
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜    
                     
／                    
ＤＥＮＳＩＴＹ ＰＥＲＩＯＤ    ２／４
  ９９９９．９９９
                   μｓ
ＣＯＭＰ． ＦＡＣＴＯＲ        
   １．７０８３５
                     
                     
    
                     
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
ＴＥＭＰＥＲＡＴＵＲＥ       ３／４
    −２３．００
                   Ｃ 
ＰＲＥＳＳＵＲＥ       
    ０．００００
                  ＭＰａ
                     
    
                     
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
ＭＯＬＥＣＵＬＡＲ ＷＥＩＧＨＴ  ４／４
    ４１．０３５
                ｇ／ｍｏｌ
ＳＰＥＣＩＦＩＣ ＷＥＩＧＨＴ
     １．４１７
                     
                     
    
                     
                     
 ＭＯＤＥ｜ＥＲＲ．｜    ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜    ｜ＤＯＷＮ
E-880TM-3-E
3
5.4.9 EL4321 Density Computer (oscillating spool densitometer, gas service)
←RUN mode screen 1
Pressing function key “PAGE UP” switches the screen to the next screen.
“DENSITY”: Density
“DENSITY (C)”: Density (corrected)
※ Measurement units, exponent, and indicated values vary with actual
settings (SET mode).
※ The placement of decimal point in uncorrected and corrected density
readings varies with the measurement units selected. (For the decimal
point of uncorrected and corrected density, see “① Density calculation
unit setup (UNIT)” on page 125.)
←RUN mode screen 2
Pressing (the) function key “PAGE UP” switches the screen to the next screen.
“DENSITY PERIOD”: Density period
“COMP. FACTOR”: T/P correction factor×quadratic correction factor
※ The placement of decimal point in density period reading varies with the
measurement unit selected. (For the decimal point of density period, see
“① Density pulse input unit setup (UNIT)” on page 72.)
←RUN mode screen 3
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing function key “PAGE DOWN” switches the screen to the previous screen.
“TEMPERATURE”: Temperature
“PRESSURE”: Pressure
※ The placement of decimal point in temperature or pressure reading varies
with the measurement unit selected. (For the decimal point of temperature,
see “① Temperature input unit setup (UNIT)” on page 51.) For the decimal
point of pressure, see “① Pressure input unit setup (UNIT)” on page 57.)
←RUN mode screen 4
Pressing function key “PAGE DOWN” switches the screen to the previous screen.
“MOLECULAR WEIGHT”: Molecular weight
“SPECIFIC WEIGHT”: Specific weight
