Oval EL4101 - Pressure Input Submenu Screen

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＰＲＥＳＳ． ＩＮＰＵＴ        

・ＵＮＩＴ               
                  ＭＰａ
 ・ＢＡＳＥ ＳＣＡＬＥ         
         ＋０．０００００ Ｅ＋０
 ・ＦＵＬＬ ＳＣＡＬＥ         
         ＋１．０００００ Ｅ＋０
 ・ＵＮＤＥＲ ＡＬＡＲＭ ＰＯＩＮＴ  
         −３．１２５００ Ｅ−２
                     
↓−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＰＲＥＳＳ． ＩＮＰＵＴ        

・ＵＮＩＴ               
                   ゜Ｃ
 ・ＣＯＮＳＴＡＮＴ           
         ＋１．０００００ Ｅ＋１
                     
                     
                     
                     
                     
−−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ
                     
／                    
↑−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＰＲＥＳＳ． ＩＮＰＵＴ        

・ＯＶＥＲ ＡＬＡＲＭ ＰＯＩＮＴ   
         ＋１．１２５００ Ｅ＋１
 ・ＵＮＤＥＲ ＦＡＬＬＢＡＣＫ    
         ＋０．０００００ Ｅ＋０
 ・ＯＶＥＲ ＦＡＬＬＢＡＣＫ     
         ＋１．０００００ Ｅ＋１
 ・ＳＭＯＯＴＨＩＮＧ ＣＯＥＦ．   
         ＋５．０００００ Ｅ−１
                     
−−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ
② Constants input
E-880TM-3-E

（2）Pressure input submenu screen
At the submenu, move the cursor to the desired item to be set up with the up and down arrow keys.
At the touch of function key “ENTR”, the screen switches to the setup screen of the item desired.
① 4 to 20mA and 1 to 5V input
① Pressure input unit setup (UNIT) p. 57
③ Pressure input baseline setup (BASELINE) p. 58
④ Pressure input full scale setup (FULL SCALE) p. 58
⑤ Pressure input under alarm point setup (UNDER ALARM POINT) p. 59
To the setup screen pointed by the cursor
SET mode main menu screen ⇒ 6.2 SET mode main menu screen p. 36
⑥ Pressure input over alarm point setup (OVER ALARM POINT) p. 59
⑦ Pressure input under fallback level (UNDER FALLBACK) p. 59
⑧ Pressure input over fallback level (OVER FALLBACK) p. 60
⑨ Pressure input smoothing factor setup (SSMOOTHING COFE.) p. 60
① Pressure input unit setup (UNIT) p. 57
② Pressure input constant (CONSTANT) p. 58
To the setup screen pointed by the cursor
SET mode main menu screen ⇒ 6.2 SET mode main menu screen p. 36
To the setup screen pointed by the cursor
SET mode main menu screen ⇒ 6.2 SET mode main menu screen p. 36
