Oval EL4101 - ⑨ Density Calculation - Air Temperature During Calibration (AIR TEMP.); ⑩ Density Calculation - Density Period with Air (AIR PERIOD); ⑪ Density Calculation - Density with Water (WATER DENS.)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＡＩＲ ＰＥＲＩＯＤ        
         ＋８．８５６８０ Ｅ＋３
                     
                     
                     
＋８．８５６８０  
       Ｅ＋３
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＡＩＲ ＴＥＭＰ．        
         ＋２．０００００ Ｅ＋１
                     
                     
                     
＋２．０００００  
       Ｅ＋１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＷＡＴＥＲ ＤＥＮＳ．        
         ＋９．９８１００ Ｅ＋２
                     
                     
                     
＋９．９８１００  
       Ｅ＋２
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
E-880TM-3-E
11
⑨ Density calculation - air temperature during calibration (AIR DENS.)
The air density during calibration is set up here for density calculation.
Density calculation setup submenu screen p. 112
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In SYS mode density input (① Density input type setup (TYPE) on page
156), if NONE is chosen for the input type, this menu will not be shown.
※ For the unit to be set here, the unit set at the temperature unit setup
(① Temperature input unit setup (UNIT) on page 51) is used. Make sure of
the unit before you set up.
⑩ Density calculation - density period with air (AIR PERIOD)
The density period with air is set up here for density calculation.
Density calculation setup submenu screen p. 112
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In SYS mode density input (① Density input type setup (TYPE) on page
156), if NONE is chosen for the input type, this menu will not be shown.
※ For the unit to be set here, the unit set at the density pulse unit setup
(① Density pulse input unit setup (UNIT) on page 72) is used. Make sure
of the unit before you set up.
⑪ Density calculation - density with water (WATER DENS.)
The density with water is set up here for density calculation.
Density calculation setup submenu screen p. 112
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In SYS mode density input (① Density input type setup (TYPE) on page
156), if NONE is chosen for the input type, this menu will not be shown.
※ For the unit to be set here, the unit set at the unit setup in density
calculation unit setup (① Density calculation input unit setup (UNIT) on
page 114) is used. Make sure of the unit before you set up.
