Oval EL4101 - ① Temperature Compensation - Refeference Temperature Setup (REF. TEMP.); ② Temperature Compensation - Coefficient a Setup (COEFFICIENT (A)); ③ Temperature Compensation - Coefficient B Setup (COEFFICIENT (B))

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＴＥＭＰ． ＣＯＭＰＥＮ．  


ＣＯＥＦＦＩＣＩＥＮＴ（ａ）    
         ＋１．０００００ Ｅ＋０
                     
                     
                     
＋１．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＴＥＭＰ． ＣＯＭＰＥＮ．   


ＣＯＥＦＦＩＣＩＥＮＴ（ｂ）    
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＴＥＭＰ． ＣＯＭＰＥＮ． 


ＲＥＦ． ＴＥＭＰ．         
         ＋１．５００００ Ｅ＋１
                     
                     
                     
＋１．５００００  
       Ｅ＋１
−−−−−−＜ＩＮＰＵＴＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
E-880TM-3-E
8
① Temperature compensation - reference temperature setup (REF. TEMP.)
The reference temperature of temperature compensation coefficient is up here.
※ For the unit to be set here, the unit set at the temperature input unit setup (① Temperature input
unit setup (UNIT) on page 51) is used. Make sure of the unit before you set up.
Temp. compensate submenu screen p. 97
② Temperature compensation - coefficient a setup (COEFFICIENT (a) )
Coefficient a of temperature compensation coefficient is set here.
Temp. compensate submenu screen p. 97
③ Temperature compensation - coefficient b setup (COEFFICIENT (b) )
Coefficient b of temperature compensation coefficient is set here.
Temp. compensate submenu screen p. 97
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown unless the temperature input type
(① Temperature input type setup (TYPE) on page 154) is set to ”NONE”.
※ For the unit to be set here, the unit set at the temperature input unit setup
(① Temperature input unit setup (UNIT) on page 51) is used. Make sure of
the unit before you set up.
←Numerical value setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
←Numerical value setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
