Oval EL4101 - ⑥ Viscosity Compensation (Μ) - Viscosity Μ3 Setup (Μ3); ⑦ Viscosity Compensation (Μ) - Frequency Setup 1 Thru 9 (FREQUENCY 1 Thru 9); ⑧ Viscosity Compensation (Μ) - Meter Error Setup 1 Thru 93 (ERROR 1 Thru 93)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＶＩＳＣＯＳＩＴＹ ＣＯＭＰ．（μ） 


ＦＲＥＱＵＥＮＣＹ１         
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−＜ＩＮＰＵＴＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＶＩＳＣＯＳＩＴＹ ＣＯＭＰ．（μ） 


ＥＲＲＯＲ１１            
         ＋０．０００００ Ｅ＋０
                     
                     
                     
＋０．０００００  
       Ｅ＋０
−−−−−−＜ＩＮＰＵＴＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＶＩＳＣＯＳＩＴＹ ＣＯＭＰ．（μ）


μ３   
         ＋２．０００００ Ｅ＋０
                     
                     
                     
＋２．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
E-880TM-3-E
13
⑥ Viscosity compensation (μ) - viscosity μ3 setup (μ3)
Coefficient μ3 in viscosity compensation is set up here.
Viscosity compensation ( μ ) submenu screen p. 134
⑦ Viscosity compensation (μ) - frequencies 1 thru 9 setup (FREQUENCIES 1 thru 9)
Frequencies (setpoints) are set up here.
Viscosity compensation ( μ ) submenu screen p. 134
⑧ Viscosity compensation (μ) - error 11 thru 93 setup (ERROR 11 thru 93)
Meter errors for the respective fluid viscosity and fluid velocities are set up here.
Viscosity compensation ( μ ) submenu screen p. 134
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ For the unit to be set here, the unit set at the unit setup of viscosity
compensation (① Viscosity compensation (μ) unit setup (UNIT) on page
135) is used. Make sure of the unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ The unit to be set here is “Hz”. Make sure of the unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ The unit to be set here is “%”. Make sure of the unit before you set up.
