Oval EL4101 - ⑥ Temperature Input over Alarm Point Setup (over ALARM POINT); ⑦ Temperature Input under Fallback Levlel up (under FALLBACK); ⑧ Temperature Input over Fallback Level Setup (over FALLBACK)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＴＥＭＰ． ＩＮＰＵＴ         


ＯＶＥＲ ＦＡＬＬＢＡＣＫ    
         ＋３．５５０００ Ｅ＋１
                     
                     
                     
＋３．５５０００  
       Ｅ＋２
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＴＥＭＰ． ＩＮＰＵＴ         


ＯＶＥＲ ＡＬＡＲＭ ＰＯＩＮＴ   
         ＋３．５００００ Ｅ＋１
                     
                     
                     
＋３．５００００  
       Ｅ＋２
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＴＥＭＰ． ＩＮＰＵＴ         


ＵＮＤＥＲ ＦＡＬＬＢＡＣＫ    
         −５．５００００ Ｅ＋１
                     
                     
                     
−５．５００００  
       Ｅ＋１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
E-880TM-3-E
3
⑥ Temperature input over alarm point setup (OVER ALARM POINT)
The over alarm point with respect to the temperature input is set up here.
To temp. input submenu screen p. 50
⑦ Temperature input under fallback level setup (UNDER FALLBACK)
The under fallback level with respect to the temperature input is set up here.
To temp. input submenu screen p. 50
⑧ Temperature input over fallback level setup (OVER FALLBACK)
The over fallback level with respect to the temperature input is set up here.
To temp. input submenu screen p. 50
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown if the temperature input type
(① temperature input type setup (TYPE) on page 154) is set to “NONE”.
※ For the unit to be set here, the unit set at the temperature input unit setup
(① Temperature input unit setup (UNIT) on page 51) is used.
Make sure of the unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown if the temperature input type
(① temperature input type setup (TYPE) on page 154) is set to “NONE”.
※ For the unit to be set here, the unit set at the temperature input unit setup
(① Temperature input unit setup (UNIT) on page 51) is used.
Make sure of the unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In the SYS mode, this item is not shown if the temperature input type
(① temperature input type setup (TYPE) on page 154) is set to “NONE”.
※ For the unit to be set here, the unit set at the temperature input unit setup
(① Temperature input unit setup (UNIT) on page 51) is used.
Make sure of the unit before you set up.
