Oval EL4101 - Blend Input Submenu Screen

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ    

・ＵＮＩＴ               
                    ％
 ・ＢＡＳＥ ＳＣＡＬＥ         
         ＋０．０００００ Ｅ＋０
 ・ＦＵＬＬ ＳＣＡＬＥ         
         ＋１．０００００ Ｅ＋２
 ・ＵＮＤＥＲ ＡＬＡＲＭ ＰＯＩＮＴ  
         ＋０．０００００ Ｅ＋０
                     
↓−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ 
                     
／                    
↑−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ      

・ＯＶＥＲ ＡＬＡＲＭ ＰＯＩＮＴ   
         ＋１．０００００ Ｅ＋２
 ・ＵＮＤＥＲ ＦＡＬＬＢＡＣＫ    
         ＋０．０００００ Ｅ＋０
 ・ＯＶＥＲ ＦＡＬＬＢＡＣＫ     
         ＋１．０００００ Ｅ＋２
 ・ＳＭＯＯＴＨＩＮＧ ＣＯＥＦ．   
         ＋５．０００００ Ｅ−１
                     
−−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ         

・ＵＮＩＴ               
                   ゜Ｃ
 ・ＣＯＮＳＴＡＮＴ           
         ＋１．０００００ Ｅ＋１
                     
                     
                     
                     
                     
−−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ
E-880TM-3-E

（1） Blend input submenu screen
At the submenu, move the cursor to the desired item to be set up with the up and down arrow keys.
At the touch of function key “ENTR”, the screen switches to the setup screen of the item desired.
① 4 to 20mA and 1 to 5V input
① Blend input unit setup (UNIT) p. 63
③ Blend input baseline setup (BASELINE) p. 63
④ Blend input full scale setup (FULL SCALE) p. 64
⑤ Blend input under alarm point setup (UNDER ALARM POINT) p. 64
To the setup screen pointed by the cursor
SET mode main menu screen ⇒ 6.2 SET mode main menu screen p. 36
⑥ Blend input over alarm point setup (OVER ALARM POINT) p. 64
⑦ Blend input under fallback level setup (UNDER FALLBACK) p. 65
⑧ Blend input over fallback level setup (OVER FALLBACK) p. 65
⑨ Blend input smoothing factor setup (SMOOTHING COEF.) p . 54
① Blend input unit setup (UNIT) p. 63
② Blend input constant (CONSTANT) p. 63
② Constant input
To the setup screen pointed by the cursor
SET mode main menu screen ⇒ 6.2 SET mode main menu screen p. 36
To the setup screen pointed by the cursor
SET mode main menu screen ⇒ 6.2 SET mode main menu screen p. 36
