Oval EL4101 - ② Density (Ρ) under Alarm Point Setup (under ALARM POINT); ③ Density (Ρ) over Alarm Point Setup (over ALARM POINT)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ（ρ）   


ＵＮＤＥＲ ＡＬＡＲＭ ＰＯＩＮＴ  
         ＋１．００００ Ｅ−１
                     
                     
                     
＋１．０００００  
       Ｅ−１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ（ρ）   


ＯＶＥＲ ＡＬＡＲＭ ＰＯＩＮＴ   
         ＋１．０００００ Ｅ＋０
                     
                     
                     
＋１．０００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
E-880TM-3-E
133
② Density (ρ) - under alarm point setup (UNDER ALARM POINT)
The under alarm point of density to be set in the parameter setup mode is set up here.
Density parameter submenu screen p. 130
③ Density (ρ) - over alarm point setup (OVER ALARM POINT)
The over alarm point of density to be set in the parameter setup mode is set up here.
Density parameter submenu screen p. 130
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ For the unit to be set here, the unit set at the density parameter unit setup
(① Density parameter unit setup (UNIT) on page 130) is used. Make sure
of the unit before you set up.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ For the unit to be set here, the unit set at the density parameter unit setup
(① Density parameter unit setup (UNIT) on page 130) is used.
Make sure of the unit before you set up.
