9.3.3 Viscosity Setup (VISCOSITY)
（1）Viscosity setup submenu screen
At the submenu, move the cursor to the desired setup item with the up and down arrow keys.
At the touch of (the) function key “ENTR”, the screen switches to the desired setup screen.
① Viscosity unit setup (VISCOSITY) p. 181
② Viscosity setup (VISCOSITY) p. 181
To the setup screen pointed by the cursor
9.2.1 PARA SET mode main menu screen p. 176
Viscosity setup submenu
screen p. 181
① Viscosity unit setup (UNIT)
The unit you can choose from are “P”, “cP”, “Pa・s”, “MPa・s”, and or “N・s/m
2
”.
Viscosity setup submenu screen p. 181
② Viscosity setup (VISCOSITY)
Viscosity is set up here.
←Unit option select
For details of option setup, see “(2) Option select setup screen (SELECT)” on
page 46.
※ The unit to be set here is the unit of the viscosity set and displayed in the
RUN mode, that of the viscosity to be set at the viscosity parameter
setup in the SET mode, and that of the viscosity to be set in the PARA
SET mode. Modifying this unit results in modifying both the unit of the
viscosity set and displayed in the RUN mode, and that of the viscosity to
be set in the SET mode (① Viscosity parameter (μ) unit setup (UNIT) on
page 135) to read in the same unit.
※ Depending on the unit chosen here, the numerical format (number of
decimal places) of viscosity set and shown in the RUN mode varies.
When you modify it, carefully take into account the count capacity and
the number of decimal places to be shown.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ For the unit to be set up here, the unit set up at the viscosity unit setup (①
Viscosity unit setup (UNIT) on page 181) is used. Make sure of the unit
before you set up.
