Oval EL4101 - EL4311 Density Computer for Mass Flowmeter (Solids Content Flow Compensated)

                     
／                    
ＤＥＮＳＩＴＹ           １／５
  ４３７．２６３７
                 ｇ／ｍｌ
ＤＥＮＳＩＴＹ（Ｃ）     
  ８００．００００
                 ｇ／ｍｌ
                     
    
                     
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜     
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜    
                     
／                    
ＴＯＴＡＬ ＣＯＵＮＴ       ２／５
       １２３
                   ｋｇ
ＴＯＴＡＬ ＣＯＵＮＴ（ＳＯＬＩＤ）
      １２３４
             ０．０１  ｋｇ
                     
    
                     
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
ＦＬＯＷ ＲＡＴＥ         ３／５
         ０
                 ｋｇ／ｈ
ＦＬＯＷ ＲＡＴＥ（ＳＯＬＩＤ）
         ０
                 ｋｇ／ｈ
                     
    
                     
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
ＴＥＭＰＥＲＡＴＵＲＥ       ４／５
      ０．００
                   ﾟＣ
ＤＥＮＳＩＴＹ ＰＥＲＩＯＤ 
   ９９９９９．９
                   μｓ
                     
    
                     
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
ＭＥＴＥＲ ＥＲＲＯＲ       ５／５
   １．０００００
                     
ＳＯＬＩＤ ＲＡＴＩＯ     
      １．００
                    ％

 
            
 ＭＯＤＥ｜ＥＲＲ．｜    ｜ＰＡＧＥ
 ＭＥＮＵ｜ＬＯＧ．｜    ｜ＤＯＷＮ
E-880TM-3-E
31
5.4.6 EL4211 Liquid Temperature Compensated Flow Computer (conversion into mass)
5.4.8 EL4311 Density Computer for Mass Flowmeter (solids content flow compensated)
←RUN mode screen 2
Pressing (the) function key “PAGE UP” switches the screen to the next screen.
“TOTAL COUNT”: Total flow (mass)
“TOTAL COUNT (SOLID)”: Total (solids content in terms of mass) flow
←RUN mode screen 5
Pressing function key “PAGE DOWN” switches the screen to the previous screen.
“METER ERROR”: Meter error correction factor
“SOLID RATIO”: Solids content ratio
←RUN mode screen 1
Pressing function key “PAGE UP” switches the screen to the next screen.
“DENSITY”: Density
“DENSITY (C)”: Density (corrected)
※ Measurement units, exponent, and indicated values vary with actual
settings (SET mode).
※ The placement of decimal point in uncorrected and corrected density
readings varies with the measurement units selected. (For the decimal
point of uncorrected and corrected density, see “① Density calculation
unit setup (UNIT)” on page 114.)
←RUN mode screen 3
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing (the) function key “PAGE DOWN” switches the screen to the previous
screen.
“FLOW RATE”: Instant flowrate (mass)
“FLOWRATE (SOLID)”: Instant (solids content in terms of mass) flowrate
←RUN mode screen 4
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing (the) function key “PAGE DOWN” switches the screen to the previous
screen.
“TEMPERATURE”: Temperature
“DENSITY PERIOD”: Density period
※ The placement of decimal point in temperature or density period reading
varies with the measurement unit selected. (For the decimal point of
temperature, see “① Temperature input unit setup (UNIT)” on page 51.
For the decimal point of density period, see “① Density pulse input unit
setup (UNIT)” on page 72.)
