Oval EL4101 - EL4201 Temp.;Press. Compensated Flow Computer (Conversion into Mass)

                     
／                    
ＴＯＴＡＬ ＣＯＵＮＴ       １／５
       １２３
             ０．０１  ｍ３
ＴＯＴＡＬ ＣＯＵＮＴ（Ｃ） 
      １２３４
             ０．１  ｋｇ
                     
    
                     
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜     
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜    
                     
／                    
ＦＬＯＷ ＲＡＴＥ         ２／５
         ０
                 ｍ３／ｈ
ＦＬＯＷ ＲＡＴＥ（Ｃ）   
         ０
                 ｋｇ／ｈ
                     
    
                     
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
ＴＥＭＰＥＲＡＴＵＲＥ       ３／５
      ０．００
                   Ｃ 
ＰＲＥＳＳＵＲＥ       
    ０．００００
                  ＭＰａ
                     
    
                     
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
ＣＯＭＰ． ＦＡＣＴＯＲ      ４／５
    １．３２０９
                     
ＭＥＴＥＲ ＥＲＲＯＲ    
   １．０００００

３α ＣＯＭＰＥＮ．       
    １．００００
                     
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
Ｔ／Ｐ ＦＡＣＴＯＲ        ５／５
    １．３２０９
                     
ＱＵＡＤＲＡＴＩＣ ＣＯＭＰＥＮ．  
    １．００００
                     
ＤＥＮＳＩＴＹ       
    １．００００
               Ｎｋｇ／ｍ３
 ＭＯＤＥ｜ＥＲＲ．｜    ｜ＰＡＧＥ
 ＭＥＮＵ｜ＬＯＧ．｜    ｜ＤＯＷＮ
E-880TM-3-E

5.4.5 EL4201 Temperature/Pressure Compensated Flow Computer (conversion into mass)
←RUN mode screen 1
Pressing (the) function key “PAGE UP” switches the screen to the next screen.
“TOTAL COUNT”: Uncorrected total flow
“TOTAL COUNT (C)”: Corrected total mass flow
※ Measurement units, exponent, and indicated values vary with actual
settings (SET mode).
←RUN mode screen 2
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing function key “PAGE DOWN” switches the screen to the previous screen.
“FLOW RATE”: Uncorrected instant flowrate
“FLOWRATE (C)”: Corrected instant mass flowrate
←RUN mode screen 3
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing function key “PAGE DOWN” switches the screen to the previous screen.
“TEMPERATURE”: Temperature
“PRESSURE”: Pressure
※ The placement of decimal point in temperature or pressure reading varies
with the measurement unit selected. (For the decimal point of temperature,
see “① Temperature input unit setup (UNIT)” on page 51. For the decimal
point of pressure, see “① Pressure unit setup (UNIT)” on page 57.)
←RUN mode screen 4
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing function key “PAGE DOWN” switches the screen to the previous screen.
“COMP. FACTOR”: Correction factor = meter error corr. factor×3α corr. factor
×T/P correction factor×quadratic corr. factor×weight conversion factor
“METER ERROR”: Meter error correction factor
“3α COMPEN.”: 3α correction factor
←RUN mode screen 5
Pressing function key “PAGE DOWN” switches the screen to the previous screen.
“T/P FACTOR”: Temperature/pressure correction factor
“QUADRATIC COMPEN.”: Quadratic correction factor
“DENSITY”: Density
※ The placement of decimal point in density reading varies with the
measurement unit selected. (For the decimal point of density, see “①
Density unit setup (UNIT)” on page 100. )
