Oval EL4101 - EL4401 Blend Oil Temperature Compensated Flow Computer

                     
／                    
ＴＯＴＡＬ ＣＯＵＮＴ       １／３
       １２３
          １０  ｍ３（ｎｏｒ）
ＴＯＴＡＬ ＣＯＵＮＴ（Ｃ） 
      １２３４
               １０  ｋｇ
ＦＬＯＷ ＲＡＴＥ（Ｃ）        
         ０
            ｍ３／ｈ（ｎｏｒ）
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＲＡ
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＳＥＴ 
                     
／                    
ＴＥＭＰＥＲＡＴＵＲＥ       ２／３
     ５０．００
                   Ｃ 
ＢＬＥＮＤ ＰＥＲＣＥＮＴ
     ５０．００
                   ％




 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
                     
／                    
ＯＶＥＲＡＬＬ ＥＲＲＯＲ     ３／３
   １．９６７８７
                     
ＶＣＦ
   １．０００００
                    

     
              
 ＭＯＤＥ｜ＥＲＲ．｜ＰＡＧＥ｜ＰＡＧＥ 
 ＭＥＮＵ｜ＬＯＧ．｜  ＵＰ｜ＤＯＷＮ
E-880TM-3-E
33
5.4.10 EL4401 Blend Oil Temperature Compensated Flow Computer
←RUN mode screen 1
Pressing function key “PAGE UP” switches the screen to the next screen.
“TOTAL COUNT”: Total flow
“TOTAL COUNT (C)”: Total (corrected) flow
“FLOW RATE”: Instant (corrected) flowrate
※ Measurement units, exponent, and indicated values vary with actual
settings (SET mode).
←RUN mode screen 2
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing function key “PAGE DOWN” switches the screen to the previous screen.
“TEMPERATURE”: Temperature
“BLEND PERCENT”: Blend proportion
※ The placement of decimal point in temperature and blend input reading
varies with the measurement unit selected. (For the decimal point of
temperature, see “① Temperature input unit setup (UNIT)” on page 51.
For the decimal point of blend input, see “① Blend input unit setup
(UNIT)” on page 63.)
←RUN mode screen 3
Pressing function key “PAGE UP” switches the screen to the next screen;
pressing function key “PAGE DOWN” switches the screen to the previous screen.
“OVERALL ERROR”: Correction factor = 3α correction factor×meter error
correction factor
“VCF”: Compression coefficient
