Remote control commands
R&S
®
RTM3000
448User Manual 1335.9090.02 ─ 09
See also: PROBe<m>:SETup:ADVanced:ZADJust on page 448.
Suffix:
<m>
.
1..4
Selects the input channel. The number of channels depends on
the instrument.
Usage: Event
PROBe<m>:SETup:ADVanced:ZADJust <ZeroAdjustValue>
This command is relevant only for R&S RT-ZCxxB current probes. It sets the waveform
to zero position. It corrects the effect of a voltage offset or temperature drift.
Suffix:
<m>
.
1..4
Selects the input channel. The number of channels depends on
the instrument.
Parameters:
<ZeroAdjustValue> Range: -100 to 100
*RST: 0
Default unit: %
PROBe<m>:SETup:PRMode <ZMMeasMode>
This command is relevant only for R&S RT-ZM probes. It sets the measurement mode
of modular probes. You can switch between singleended, differential and common
mode measurements without reconnecting or resoldering the probe.
Suffix:
<m>
.
1..4
Selects the input channel. The number of channels depends on
the instrument.
Parameters:
<ZMMeasMode> DMODe | CMODe | PMODe | NMODe
DMODe
Differential mode input voltage (V
dm
), the voltage between the
positive and negative input terminal.
CMODe
Common mode input voltage (V
cm
), the mean voltage between
the positive and negative input terminal vs. ground.
PMODe
Positive single-ended input voltage (V
p
). The voltage between
the positive input terminal and ground.
NMODe
Negative single-ended input voltage (V
N
). The voltage between
the negative input terminal and ground.
*RST:
DMODe
Waveform setup
