Copy to offset
Sets the offset to the mean value of the ProbeMeter's DC measurement.
Remote command:
PROBe<m>:SETup:ADVanced:PMToffset on page 447
ProbeMeter
®
Shows the measurement result of the integrated R&S ProbeMeter of active
Rohde & Schwarz voltage probes.
If a single-ended or power rail probe is connected, the ProbeMeter measures DC vol-
tages between the probe tip and ground connection and enables ground-referenced
measurements of voltages.
If a differential probe is connected, the ProbeMeter measures differential and common
mode voltages.
The ProbeMeter measures continuously and in parallel to the measurements of the
oscilloscope. The results are shown below the grid. You can switch off the ProbeMeter
using the button below the the results.
Remote command:
PROBe<m>:PMETer:VISibility, PROBe<m>:SETup:OFFSwitch on page 450
PROBe<m>:PMETer:RESults:SINGle?, PROBe<m>:SETup:DCOFfset?
on page 451
PROBe<m>:PMETer:RESults:COMMon? on page 451
PROBe<m>:PMETer:RESults:DIFFerential? on page 451
PROBe<m>:PMETer:RESults:NEGative? on page 452
PROBe<m>:PMETer:RESults:POSitive? on page 452
MicroButton
Active Rohde & Schwarz probes have a configurable micro button on the probe head.
Pressing this button, you can perform an action on the instrument directly from the
probe. During internal automatic processes the button is disabled, for example, during
self alignment, autoset, and find level.
Select the action that you want to start from the probe.
"None"
Select this option to prevent unwanted actions due to unintended
usage of the micro button.
"Continuous"
Starts continuous acquisition, like the [Run Stop] key. The acquisition
is running as long as you press the micro button again.
"Single"
Starts one acquisition.
"Autoset"
Starts the autoset procedure.
"Probe Menu"
Opens the probe menu.
"ProbeMeter
®
"
Shows or hides the result of the ProbeMeter measurement.
"Screenshots"
Saves a screenshot.
"OneTouch"
Initiates the assigned OneTouch actions, same effect as pressing the
key.
"Copy to off-
set"
Sets the offset to the mean value of the ProbeMeter's DC measure-
ment.
