TRIGger:A:CAN:TYPE <TriggerType>
Specifies the trigger mode for CAN.
Parameters:
<TriggerType> STOFrame | EOFrame | ID | IDDT | FTYPe | ERRCondition
STOFrame
Start of frame
EOFrame
End of frame
ID
Sets the trigger to a specific message "Identifier" or an "Identi-
fier" range.
Specify the identifier with TRIGger:A:CAN:ITYPe, TRIGger:
A:CAN:ICONdition and TRIGger:A:CAN:IDENtifier.
IDDT
Sets the trigger to a combination of "Identifier and Data" condi-
tion. The instrument triggers at the end of the last byte of the
specified data pattern.
Specify the "Identifier" (see ID), and the "Data" with TRIGger:
A:CAN:DLC, TRIGger:A:CAN:DCONdition and TRIGger:A:
CAN:DATA.
FTYPe
Triggers on a specified "Frame".
Specify the frame type with TRIGger:A:CAN:FTYPe.
ERRCondition
Identifies various errors in the frame.
Specify the "Error" with TRIGger:A:CAN:ACKerror,
TRIGger:A:CAN:BITSterror, TRIGger:A:CAN:CRCerror
and TRIGger:A:CAN:FORMerror.
*RST:
STOF
TRIGger:A:CAN:FTYPe <FrameType>
Specifies the frame type to be triggered on if TRIGger:A:CAN:TYPE is set to FTYPe.
Parameters:
<FrameType> DATA | REMote | ERRor | OVERload | ANY
*RST: ERR
TRIGger:A:CAN:ITYPe <IdentifierType>
Selects the length of the identifier: 11 bit for CAN base frames, or 29 bits for CAN
extended frames.
The command is relevant if TRIGger:A:CAN:TYPE is set to ID, IDDT, or FTYPe (data
and remote frames).
